D5650.PDF

Conf. OIE 1998, 289-302
STRATEGIES FOR THE CONTROL OF CLASSICAL SWINE FEVER,
INCLUDING THE APPLICATION OF MODERN VACCINES
V. Moennig
Institute of Virology, School of Veterinary Medicine, Buenteweg 17, D-30559 Hannover, Germany
Original: English
Summary: Classical swine fever (CSF) is an infectious viral disease which has severe economic impact
on the pig industry of several European countries. Whereas European Union (EU) Member States and
other Western European countries are almost free of the disease in domestic pigs, the CSF situation in
many Central and Eastern European countries remains unclear. The number of outbreaks in domestic
pigs decreased in the EU in the 1990s, but financial losses increased greatly due to changes in the
structure of the pig industry and control policy. The concentration of pigs and farms in some regions of
Europe and long distance trade increased the risk of spreading the disease and the number of pigs
affected by control measures. Primary CSF outbreaks are mostly due to (illegal) swill feeding.
In some areas of Europe, CSF has become endemic in the wild boar population. This poses a constant
risk for domestic pigs. Knowledge about the epidemiological situation of CSF in wild boar is insufficient
in many countries.
Laboratory diagnosis has improved markedly during the last decade. Most European countries are
equipped for CSF diagnosis and participate in international inter-laboratory comparison tests in order to
standardise CSF diagnosis. Molecular typing of CSF virus isolates has become a valuable tool for
epidemiology. Diagnostic capacities for emergency situations must be considered in national
contingency plans.
Since the prevalence of infected animals has decreased, the EU pursues a non-vaccination policy to
control CSF. This facilitates the internal market and fulfils the requirements of the international market.
Several other European countries have adopted this policy.
Although this control strategy is widely accepted today, legislation needs some amendment based on the
scientific evaluation of the recent CSF epidemics in Europe. Currently, two subunit marker vaccines are
undergoing the licencing procedure. These vaccines might be a future option for restricted use in
emergency situations.
Essentially, the success of control programmes depends on education and awareness of all parties
involved, i.e. farmers, practitioners and Veterinary Services.
1. INTRODUCTION
Classical Swine Fever (CSF) is one of the most economically important viral infectious diseases of domestic and wild
pigs and is classified as an OIE List A disease. After implementation of consequent control measures, several countries,
including Australia, Canada, New Zealand, United States of America (USA), and some Member States of the European
Union (EU), succeeded in eradicating the virus. In most other parts of the world the CSF virus is present, causing
considerable economical damage. The manifestation of the infection may vary greatly depending on the age of the
animal and the virus virulence. Young animals often display the acute classical form, with high fever, haemorrhages
and high mortality. Alternatively, the chronic and ultimately fatal form may obscure the characteristic classical picture
in young animals. Older animals often show only mild clinical symptoms. Like all pestiviruses, CSF virus may pass
through the placenta of pregnant animals, infecting foetuses and leading incidentally to the birth of persistently viremic
piglets. The latter develop late onset CSF later in life and die from CSF. The multitude of possible clinical signs very
often hampers prompt diagnosis of primary outbreaks (photo 1).
- 289 -
Conf. OIE 1998
In order to compile information about occurrence, diagnosis and eradication in OIE Member Countries, a questionnaire
was prepared and sent to each country. Out of 50 countries, 33 provided the requested information to OIE. Seventeen
countries did not respond.
The following countries made information available: Andorra, Armenia, Austria, Belarus, Croatia, Cyprus, Czech
Republic, Denmark, Estonia, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Moldavia, Netherlands, Norway, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden,
Switzerland, Ukraine, United Kingdom and Uzbekistan.
2. ETIOLOGY
The causative agent of CSF is a small (40-60 nm) enveloped ribonucleic acid (RNA) virus with a single stranded RNA
genome with positive polarity. CSF virus belongs to the pestivirus genus of the Flaviviridae family (29). It is related to
the bovine viral diarrhoea (BVD) virus and the border disease (BD) virus of sheep. The genomic sequence of about
12,000 bases is known and infectious copy deoxyribonucleic acid (cDNAs) have been produced in several laboratories
(16, 19, 20). The viral RNA codes for four structural and seven nonstructural proteins (17, 18). The virus is relatively
stable in moist excretions and fresh meat products, including ham and salami type sausages (22). However, it is readily
inactivated by detergents, lipid solvents, proteases and common disinfectants.
3. CLINICAL SIGNS
The incubation period is seven to ten days. The clinical signs of CSF are extremely variable (18, 26). Infected pigs
develop pyrexia and leukopenia. Petechial haemorrhages of the outer skin and mucosae are the most typical sign
although they are not seen consistently (photos 2 & 3). Central nervous system disorders and obstipation followed by
diarrhoea may also be characteristic clinical findings.
The severity of clinical signs largely depends on the age of the animal and viral virulence. Usually young animals are
affected more severely than older animals. In older breeding pigs the course of the infection is often mild or even
subclinic.
Acute and chronic courses of CSF are known. All courses of the infection have in common that the animals are viremic
at least as long as they show clinical signs. Deaths occurs two to three weeks after infection (acute course) or after up to
three months (chronic course).
The outcome of transplacental infection of foetuses depends largely on the time of gestation (26) and may result in
abortions and stillbirths, mummifications, malformations or the birth of weak or persistently viremic piglets (15) (photo
4). Although persistently infected offspring may be clinically normal at birth, they invariably die from CSF. Survival
periods of 11 months after birth have been observed. This course of infection is referred to as 'late onset CSF' (25).
4. PATHOLOGY AND PATHOGENESIS
Under natural conditions the most frequent route by which the CSF virus enters its host is oronasal. Major target cells
for the virus are endothelial cells, lymphoreticular cells, macrophages, and some kinds of epithelial cells. Pathological
findings vary according to clinical signs (18, 25).
Prenatally, at the early phases of ontogenesis, the virus affects organ differentiation and leads to malformations.
In postnatal infections, lesions are generally caused by widespread thrombosis and/or endothelial damage, inducing
haemorrhagic diathesis and petechiation. Bronchopneumonia is another regular feature. In a high proportion of fatal
cases, histopathology of the brain shows a non-suppurative encephalitis with severe vasculitis. Severe
thrombocytopenia is a consistent finding. The terminal stage of acute infection is associated with a marked depletion of
B lymphocytes in the circulatory system as well as in lymphoid tissues (24).
- 290 -
Conf. OIE 1998
Photo 1: Pox-like skin lesions
Lésions cutanées varioliformes
Оспоподобные кожные поражения
Photo 2: Skin haemorrhages and necroses on the ear edges
Hémorragies et nécroses cutanées au bord des oreilles
Кожные геморрагии и некрозы по краям уха
- 291 -
Conf. OIE 1998
5. IMMUNOLOGY
Like all pestiviruses, the CSF virus is immuno-suppressive during acute infection. Pigs that have recovered are
protected against CSF for several years or even for their lifetime. Neutralising antibodies are detectable two weeks after
infection at the earliest. In pigs with chronic CSF, neutralising antibodies are detectable at the end of the first month
postinfection for a few days and disappear afterwards. Persistently viremic, in utero infected pigs seldom produce
specific antibodies.
Maternal antibodies have a half-life of approximately 14 days. Passive immunity generally protects piglets against
mortality during the first five weeks of life, but not against virus replication and shedding. Little is known about cellmediated immunity against CSF.
6. DIAGNOSIS OF CSF AND LABORATORY FACILITIES
Clinical diagnosis is of prime importance for the detection of CSF. However, it may prove difficult and many primary
outbreaks are initially not recognised as CSF, because clinical signs are often variable and non specific. This applies
especially for older animals in breeding herds. In general, CSF should be considered whenever a disease with high
body temperature that does not react to treatment is diagnosed. This is especially relevant in regions where CSF has
occurred during the last 12 months in domestic pigs or wild boar. Veterinarians, farmers and hunters should be highly
aware of the risk.
A modern and efficient laboratory diagnosis is an essential tool for CSF control. Monitoring of the status of the pig
population in 'peace time' and early detection of CSF depend on reliable diagnostic methods and adequate laboratory
facilities.
In order to discover CSF infected herds at an early stage, it is important to identify the right animals for laboratory
investigation. These are clinically sick animals and should be tested virologically. Random sampling is not suitable for
CSF diagnosis. It may be used for epidemiological purposes, such as monitoring and serological prevalence studies.
6.1.
Virology
The 'gold standard' for CSF diagnosis is virus isolation. CSF virus can be isolated from buffy coat cells or organ
suspensions of viremic animals. Suitable organs are spleen, tonsils, lymphnodes, parotid glands and kidneys
(1, 3).
The samples are incubated on susceptible cell cultures of porcine origin. As the CSF virus is
non-cytopathogenic, CSF specific antibodies are a prerequisite for detection of the virus in cell culture.
Differentiation of the CSF virus from ruminant pestiviruses can be achieved using monoclonal antibodies (1, 3,
6). The virus isolation protocol requires at least three days and is labour intensive. A rapid diagnostic test for
CSF is based on the demonstration of viral antigen in organ tissue sections using conjugated antibodies for direct
immunofluorescence (fluorescent antibody test, FAT). To screen large numbers of animals in herds suspect of
being recently infected by CSF, virus antigen capture enzyme-linked immunosorbent assays (AgC-ELISAs) can
be used for the detection of viral antigen in blood samples. However, the latter tests are less sensitive than virus
isolation.
Recently, detection of viral RNA has become an additional option for laboratory diagnosis. In particular, the
5'-nontranslated region of the genome has been used for amplification by the reverse transcriptase polymerase
chain reaction (RT-PCR). Subsequent nucleotide sequencing of the respective region allows discrimination
between different CSF virus isolates (9, 14). The OIE Reference Laboratory for CSF in Hannover, Germany,
keeps an extensive computer data base on CSF virus isolates including epidemiological and virus type
information data.
The 'molecular epidemiology' based on the above technique has become a useful tool and may well support
epidemiological investigations (tracing on/back). Typing of CSF virus isolates of at least each primary outbreak
in domestic pigs and isolates originating from wild boar is desirable. OIE Member Countries are encouraged to
send respective materials to the above-mentioned OIE Reference Laboratory.
- 292 -
Conf. OIE 1998
Photo 3: Multiple petechial haemorrhages on different wild boar organs (acute CSF)
Pétéchies multiples de différents organes chez un sanglier (peste porcine aiguë)
Множественные петехии в различных органах дикого кабана (острая чума свиней)
Photo 4: Aborted and mumified fetuses
Avortons momifiés
Мумифицированные выкидыши
- 293 -
Conf. OIE 1998
6.2.
Serology
Serological diagnosis of CSF is important for the detection of hidden clusters of CSF, such as breeding herds
with subclinical infection or reconvalescent animals. Furthermore, it is useful for epidemiological surveys in
wild boar.
The virus neutralisation test is the safest and most reliable method for CSF antibody detection. Porcine serum
samples are incubated with a CSF reference virus. If the serum contains antibodies for CSF the test virus will be
neutralised. However, cross-neutralising antibodies specific for ruminant pestivirus infections of pigs are
sometimes registered by this test. Differential diagnosis for ruminant pestiviruses should therefore be carried out
using a second neutralising test with ruminant pestiviruses. The neutralisation test requires two to three days and
is labour intensive. Large numbers of serum samples are therefore processed using ELISA tests. Positive or
unclear results should be retested using the neutralisation test, which is usually more sensitive and more specific.
6.3.
Laboratory facilities
Most European countries are equipped for CSF diagnosis, except for Andorra, Armenia, Iceland, Malta, Ukraine
and Uzbekistan, which use laboratories in other countries. Laboratories in some countries are only equipped for
ELISA testing. Almost all European countries with CSF laboratory facilities participate in annual international
inter-laboratory comparison tests in order to standardise and improve diagnosis. These tests are organised by the
reference laboratories and the results are discussed at international conferences.
The number of samples tested in individual countries depends largely on the country's CSF status and the CSF
monitoring programme of the pig population. Countries with CSF outbreaks usually test a large number of
samples. Monitoring programmes vary significantly within European countries. Likewise, investigation for CSF
in wild boar populations is variable and the available information is insufficient.
Diagnostic capacities are crucial for the control of CSF in case of an epidemic. Past experience shows that
capacities were often insufficient to handle large numbers of samples. The realistic assessment of emergency
situations and provision of diagnostic capacities must be part of the national contingency plan.
7. VACCINES
Immunoprophylaxis has been an important instrument to control CSF. From the beginning of the century attempts have
been made to develop vaccines against CSF using simultaneous vaccination, i.e. where live field virus and
hyperimmune serum were applied simultaneously. This procedure was efficacious but its safety was poor. The second
generation of CSF vaccines was produced from virus propagated in pigs with subsequent inactivation, e.g., using
crystal violet or formalin. These vaccines were safe but the immune response was delayed and weak, and lasted only a
few months. Vaccinated animals usually showed good clinical resistance to challenge with virulent virus, but they were
not effectively protected against infection. This was proven by the observation that virulent virus was found in foetuses
after challenge of vaccinated pregnant sows (11, 13).
In the 1940s the first experiments were made to attenuate the CSF virus by adapting it to rabbits (5, 12). After initial
setbacks, this development ultimately led to a very efficient and safe generation of live vaccines. Most of these vaccines
are based on the China-strain (C-strain) of lapinized CSF virus. C-strain vaccines were and are still being used worldwide for the control of CSF. Currently the C-strain is used in an oral immunisation field trial to control CSF in German
wild boars. C-strain vaccines induce high titres of neutralising antibodies and they are safe when used on pregnant
animals. Their efficacy is demonstrated by the observation that vaccinated pigs are protected against infections with
virulent CSF virus as early as five days after vaccination. The animals are immune throughout their economic life.
However, in light of today´s global trade policy there is a severe disadvantage in using live attenuated vaccines against
CSF: vaccinated and field-virus-infected animals cannot be distinguished. The antibody pattern induced by the vaccine
virus resembles that of reconvalescent animals; thus field virus infections may be masked by vaccination.
For this reason, the European Union (EU) pursues a non-vaccination policy. Due to the recent series of CSF epidemics
in several Member States, notably Belgium, Germany, Netherlands and Spain, it became apparent that the nonvaccination policy is expensive and difficult to enforce in regions with high pig densities. Emergency vaccination using
conventional vaccines would result in prolonged and thereby prohibitive trade restrictions.
The use of a marker vaccines against CSF could overcome this dilemma, and a first generation of such vaccines has
been developed in recent years. These vaccines are under final investigation in order to determine their value under
- 294 -
Conf. OIE 1998
field conditions. A marker vaccine should induce protective immunity. The immune response must be distinguishable
from field virus infection and the companion diagnostic test must detect all infected animals. Immunity should be
induced rapidly (e.g. two weeks) and be long lasting (e.g., six months). Vaccinated pigs must be protected against
natural challenge and must not show clinical signs or shed field virus. Sows should be protected against transplacental
infection of foetuses. The vaccine should be safe and effective for young piglets and one administration should be
sufficient. Subunit vaccines consist of single viral surface proteins, which are sufficient for the induction of protective
immunity. Both current vaccines containing viral glycoprotein E2 are produced using recombinant DNA technology.
The respective gene is expressed in baculoviruses grown in insect cells (27). Since these cells are able to glycosylate
proteins, the resulting viral glycoprotein is expressed in a 'natural' way. CSF subunit vaccines are safe and so far their
protective potency is promising, though inferior to live vaccines. Vaccinated animals may be distinguished from
infected pigs using an ELISA based on a different viral protein as diagnostic antigen, for example, the surface
glycoprotein Erns or the nonstructural protein NS2-3. However, not all criteria are well defined yet, and the technical
merits of CSF subunit marker vaccines have not yet been confirmed. Data are expected to be available by the year
1999.
CSF marker vaccines might be improved by future vaccine generations, e.g., viral vector vaccines (10, 21, 28), DNA
vaccines and molecular altered infectious cDNA clones of CSF virus (17, 19, 20).
8. EPIDEMIOLOGY
8.1.
Pig population and occurrence of CSF
CSF occurs in nearly all continents and countries where pigs are kept except for Australia and North America
(CSF eradicated) and some Western European countries (e.g. Denmark, England, Finland, Greece, Ireland,
Norway and Sweden), which have been free of CSF for several decades.
Both the structure and density of pig populations have a considerable influence on the epidemiology and control
of CSF. In recent years high pig concentrations (animal and farm density) were built up in several European
regions. The probability of spreading the disease in those areas is much higher than in lower density areas. Long
distance animal trade was intensified and contributes to the problem. Therefore, it is very important to obtain
quick, reliable and complete information about trade movements and contact farms.
The structure of the European pig industry displays a wide variation between regions and countries (Table 1). In
some countries domestic pigs are kept preferably in small farms (more than 50% of farms have less than 20 pigs
in Andorra, Estonia, Germany, Latvia, Lithuania, Portugal, Romania, Slovenia, Spain, Sweden and Ukraine). In
other countries, domestic pigs are kept preferably in bigger farms (more than 50% of farms with more than 500
pigs: Armenia, Cyprus, Czech Republic, Finland, France, Greece and Slovakia). The remaining countries show a
high percentage of pig farms with between 20 and 500 pigs (Belarus, Croatia, Denmark, Iceland, Luxembourg,
Malta, Netherlands, Norway, Switzerland, United Kingdom and Uzbekistan).
Wild boar and domestic pigs are equally susceptible to CSF virus infection (7). The occurrence, density and
behaviour of wild boar populations are important for the epidemiology of CSF. Wild boar populations appear to
be increasing all over Europe. Present estimated populations of wild boar in European countries are shown in
Table 2.
If not disturbed, wild boar have a limited home-range and tend to be stationary, except for young boar which
tend to move. In countries that are free of CSF in domestic pigs, epidemics in wild boar are typically initiated by
swill feeding. Depending on viral virulence, the density and the size of the population, CSF epidemics in wild
boar are not always self-limiting. The wild boar might represent a permanent virus reservoir that poses a
constant threat to domestic pigs.
- 295 -
Conf. OIE 1998
Table 1: Domestic pig populations in European countries
Country
Andorra
Armenia
Austria
Belarus
Croatia
Cyprus
Czech Republic
Denmark
Estonia
Finland
France
Germany
Greece
Iceland
Ireland
Italy
Latvia
Lithuania
Luxembourg
Malta
Moldavia
Netherlands
Norway
Portugal
Romania
Slovakia
Slovenia
Spain
Sweden
Switzerland
United Kingdom
Ukraine
Uzbekistan
Total pig
population
103
54 297
3 680 000
3 680 000
1 200 000
400 000
3 900 000
11 300 000
300 000
1 400 000
14 000 000
24 700 000
1 500 000
3 537
1 700 000
8 000 000
429 400
1 120 000
77 149
80 000
776 264
15 000 000
647 000
2 230 000
6 490 000
1 800 000
583 000
18 000 000
3 800 000
1 400 000
7 350 000
9 400 000
70 000
* CSF occurrence during the last four years
Number of pig
herds
% of herds
<20 pigs
% of herds
>500 pigs
CSF*
occurrence
25
3
100 455
1 375
n.a.
158
5 700
24 738
5 462
6 500
28 000
192 239
52 000
70
3 000
44 085
86 269
426
389
120
498
21 000
5 800
10 150
2 590 000
1 148
89
301 000
10 700
17 800
12 202
2 740 000
112
100
0
n.a.**
0
30
0
15
25
92
5
3
57
<5
10
n.a.
n.a.
100
60
6
0
n.a.
8
50
70
100
13
75
86
66
47
10
99
0
0
100
n.a.
34
10
98
70
32
2
60
62
14
>80
50
n.a.
n.a.
0
25
9
20
n.a.
32
5
30
0
59
10
4
10
0
30
0
18
no
no
yes
yes
yes
no
yes
no
no
no
no
yes
no
no
no
yes
yes
no
no
no
yes
yes
no
no
no
yes
yes
yes
no
no
no
yes
no
** data not available
8.1.1. EU Member States and other Western European countries
At present the EU Member States are practically free of CSF in domestic pigs. However, sporadic or
massive new outbreaks have been observed in domestic pigs in recent years (1990 - 1998). Outbreaks in
areas with a high density of pigs have often led to extensive epidemics with most severe economic losses.
During the last four years, CSF outbreaks in domestic pigs have been observed in Austria, Belgium,
Germany, Italy, Netherlands, Spain and Switzerland (Table 1). The most recent and probably the most
costly epidemic started at the end of 1996 in a pig herd in Western Germany due to illegal swill feeding.
The virus subsequently spread to several regional pig farms (1997) and presumably from Germany to the
Netherlands and subsequently to Spain, Italy and Belgium. More than 550 confirmed outbreaks could be
attributed to this epidemic, which appears to have recently come to an end.
- 296 -
Conf. OIE 1998
Table 2: Wild boar populations in European countries and monitoring for CSF
Wild boar population
Country
Estimated
population
Andorra
Armenia
Austria
Belarus
Croatia
Cyprus
Czech Rep.
Denmark
Estonia
Finland
France
Germany
n.a.*
n.a.
n.a.
26 643
10 200
0
38 000
n.a.
10 000
300
450 000
600 000
Greece
Iceland
Ireland
Italy
Latvia
Lithuania
Luxembourg
500
0
0
n.a.
17 274
19 400
15 000
Malta
Moldavia
Netherlands
Norway
Portugal
0
1137
3 000
0
60 000
Romania
Slovakia
Slovenia
Spain
Sweden
Switzerland
United Kingdom
Ukraine
Uzbekistan
16 800
19 536
5 000
n.a.
10 000
8 000
100
43 000
n.a.
* data not available
Investigation and choice of samples
Distribution
Random
Sick wild
boar
Proximity to
outbreaks**
CSF
occurrence
overall
regional
n.a.
overall
overall
no
n.a.
n.a.
no
yes
no
n.a.
n.a.
yes
yes
no
n.a.
n.a.
no
yes
n.i.***
n.a.
yes
n.i.
no
overall
regional
overall
regional
regional
overall
yes
no
n.a.
yes
yes
yes
yes
no
n.a.
yes
yes
yes
yes
no
n.a.
no
no
yes
yes
n.i.
n.a.
n.i.
yes
yes
regional
no
no
no
n.i.
regional
overall
overall
overall
yes
yes
yes
yes
yes
no
yes
no
yes
no
yes
no
yes
yes
no
no
overall
regional
yes
yes
no
yes
yes
yes
n.i.
no
n.a.
yes
no
no
no
overall
overall
overall
overall
regional
regional
regional
overall
overall
yes
yes
yes
no
no
yes
no
no
no
yes
yes
yes
no
no
yes
no
yes
no
yes
yes
yes
no
no
yes
no
yes
no
no
yes
n.i.
n.i.
n.i.
yes
n.i.
yes
n.i.
** proximity to CSF outbreaks in domestic pigs
*** not investigated
In wild boar, CSF has been observed in Austria, France, Germany, Italy and Switzerland (Table 2). In
some areas the infection has been endemic for several years. In Germany, many primary outbreaks have
been linked to the occurrence of CSF in local wild boar populations. All Western European countries
where CSF has occurred during the last few years run a monitoring programme for CSF in wild boar,
except for Spain. Three of the seven other countries with wild boar populations (Finland, Luxembourg,
Portugal) monitor wild boar for CSF (Table 2). In the other countries (Denmark, Greece, Sweden and
United Kingdom), CSF infection in wild boar is unlikely to occur due to animal population size and
geographic location. Since almost all Western European countries made information available, the
epidemiological situation with respect to wild boar is clear in that part of Europe.
- 297 -
Conf. OIE 1998
8.1.2. Central and Eastern European countries
The situation regarding CSF in both domestic and wild swine is less clear in these countries than it is in
Western Europe. In most Central and Eastern European countries from which data are available CSF has
been observed in domestic pigs during the last decade. Cyprus and Uzbekistan were free of CSF. With
regard to the last four years, CSF occurred in Belarus, Croatia, Czech Republic, Latvia, Moldavia,
Slovakia, Slovenia and Ukraine (Table 1).
In Czech Republic, Latvia, Slovakia and Ukraine, CSF has been observed in wild boar. Croatia,
Lithuania and Romania have not detected CSF infection in wild boar whereas data from the other
23 countries are not available (Table 2). The provided data shows that monitoring programmes for CSF
in wild boar have been established in all countries except for Armenia, Estonia and Uzbekistan. However,
results of the monitoring programmes have not been made available.
In order to prevent the introduction of CSF by pig or meat imports, it is essential to obtain reliable and
comprehensive information on the disease status of trade partners. Monitoring programmes are a useful
tool to determine whether a pig population is free of CSF or affected by the disease. This is most
important in the wild boar population because, compared with domestic pigs, wild boar are not under
permanent control. There is a need to considerably strengthen information systems and reporting on
epidemiology of CSF and particularly that of wild boar in Central and Eastern Europe.
8.2.
Transmission/spread of the virus
In many countries the feeding of pigs with swill is strictly forbidden. Exceptions are made when handling and
heat-treatment of swill are officially licensed. Despite these strict measures the typical source of infection in
many if not most index cases in domestic pig herds or in wild boar populations is swill feeding. Sometimes the
outbreaks are due to a failure in swill processing but in most cases swill is fed illegally without any previous
treatment. Often the farmer´s awareness of the risk and knowledge of the legislation are not sufficient. Wild boar
might pick up material contaminated with the CSF virus had been thrown away at rest places and garbage
dumps. From wild boar the virus may be transmitted directly (animal contact) or more often indirectly to
domestic pigs (contaminated equipment belonging to farmers who are hunters as well, feed contaminated by
wild boar excretions or carcasses, illegal swill feeding, contact of pigs with wild boar excretions etc.).
After introduction of the CSF virus into the first domestic pig herd (primary outbreak), the probability of the
disease spreading depends primarily on the number of contacts with other pig holdings before the disease is
noticed. In general, high risk factors are the pig and farm density in the affected region. Pig farms within a
radius of approximately 500 metres face a higher relative risk of contracting the infection when compared with
more distant farms surrounding an infected holding (23). The increasing long distance trade in the pig industry is
an additional important risk factor.
The most important routes of CSF virus transmission during epidemics are as follows:
- trade with chronically or acutely infected pigs
- transmission by persons via contaminated clothes or instruments
- "undefined" contacts in the neighbourhood of infected farms (up to 500 metres)
- indirect or direct contact with infected wild boar
- insufficiently cleaned and disinfected vehicles (transport lorries)
- (illegal) swill feeding
9. CONTROL STRATEGIES
There are two major control strategies: the first is routine vaccination while the other is exclusively based on
eradication measures without the use of vaccines.
The use of conventional vaccines prevents the differentiation between of vaccinated and field virus infected animals.
Thus the field virus may reside undetected in parts of the population. For this reason the EU banned vaccination against
CSF at the end of the 1980s. CSF is an OIE List A disease. Every suspected case has to be investigated and once it is
confirmed, the outbreak has to be notified. The preventive measures adopted for trade with third countries include that
live pigs and fresh pig meat can only be imported from regions or countries where no CSF has occurred for 12 months
and no vaccination against CSF was undertaken during the same period. Whereas the immediate neighbours of the EU
- 298 -
Conf. OIE 1998
have adopted the non vaccination policy, vaccination is allowed and mostly routinely applied by most other Central and
Eastern European countries (Table 3). In Slovakia, only emergency vaccination is carried out. Most countries use
modified live vaccines. In Armenia, Latvia, Lithuania and Slovakia, inactivated virus vaccines are used.
In the EU, eradication measures are based on stamping out (depopulation) of infected pig herds and possibly infected
contact or (partially) neighbouring herds, epidemiological investigations, clinical and virological investigations,
movement restrictions for live pigs, pig meat and other vectors which can transmit CSF within zones surrounding the
infected farm and restrictions on contact farms outside these zones (1). Especially in areas with dense pig populations,
very high numbers of pigs had to be destroyed in the course of the eradication measures dealing with the outbreaks
mentioned above. Only a minority of animals were killed due to direct involvement with the infection. Most of the pigs
had to be killed because of welfare measures.
Table 3: CSF Vaccination policy in non-EU European countries
Country
Vaccination
allowed
Routine
vaccination
Emergency
vaccination
Andorra
Cyprus
Czech Republic
Iceland
Malta
Norway
Switzerland
Uzbekistan
Lithuania
no
no
no
no
no
no
no
no
yes
no
no
no
no
no
no
no
no
no
no
no
no
no
no
no
no
n.a.*
no
inactivated virus
650 000
Slovakia
Slovenia
Armenia
Belarus
Croatia
Latvia
yes
yes
yes
yes
yes
yes
no
no
yes
yes
yes
yes
yes
n.a.
yes
yes
no
yes
modified live
modified live
inactivated virus
modified live
modified live
inactivated virus
276 500
300 000
100 000
ca. 5.000.000
2 072 112
432 593
Moldavia
Romania
Ukraine
yes
yes
yes
yes
yes
yes
yes
yes
yes
modified live
modified live
modified live
Vaccine type
Number of
vaccinated animals
1 200 000
6 500 000
12 200 000
* data not available
In principle, emergency vaccination is not contradictory with EU directives (1). Requirements related to emergency
vaccination campaigns against the CSF virus have been defined in the document 'Guidelines for a Classical Swine
Fever Emergency Vaccination Programme' (2). However, by using conventional vaccines and applying the mentioned
guidelines, the Scientific Veterinary Committee of the European Commission has calculated that vaccinated animals
would be excluded from the market for up to 600 days (4). This is economically unacceptable and so far emergency
vaccination has never been used.
With the development of a first generation marker vaccine against CSF, the possibility of an amendment of the existing
emergency vaccination regulations seems feasible. The implementation of a marker vaccine would require extensive
serological testing in the vaccinated population in order to detect field infections. However, so far no marker vaccine
has been licensed by the European Agency for Evaluation of Medicinal Products (EMEA) in London and EU Member
States demand additional data on the safety and efficacy of the vaccine before a potential use in emergency situations. It
is understood that the criteria for the use of the marker vaccine will be very stringent. Provided that all safety
requirements are met, the period of exclusion from the market could be considerably shortened (4). As soon as marker
vaccines are sufficiently investigated and licensed, the 'Guidelines for a Classical Swine Fever Emergency Vaccination
Programme' (2) are to be amended. The possible use of an emergency vaccination with marker vaccines is expected to
lower the costs incurred by current procedures, thereby adding an additional tool to the non-vaccination policy.
- 299 -
Conf. OIE 1998
In non-EU countries, CSF control measures are run by official veterinary authorities (with the exception of
Uzbekistan), insofar as data are available. Not all countries follow a national eradication programme. In Latvia and
Lithuania, voluntary programmes for pig farmers have been established. Several countries do not run a monitoring
programme to establish whether the domestic pig population is free from CSF.
In the case of an outbreak, all EU Member States and the other Western European countries execute eradication
measures according to the Council Directive 80/217/EEC. Some of the Central and Eastern European countries apply
similar measures. In some countries, only sick or clinically suspect animals are destroyed whereas all other animals of
the infected herd, herds in the neighbouring area and contact herds are vaccinated.
An unsolved problem is the control of CSF in wild boar. Both the prolonged persistence of the virus in wildlife
populations and the constant threat to pig holdings in the areas concerned require an efficient control strategy. It is
essential for veterinary officers and hunters to have profound knowledge of the structure and dynamics of the wild boar
population in their local habitat. Wild boar meta-populations (subpopulations with very limited contacts with other
ones) should be defined on the basis of their natural habitat and resources. Any kind of regulatory measures (including
hunting) should be carried out on the entire meta-population, not just on parts of it. Young wild boars (< 1 year) are the
most important virus target and play the most important role in virus spread. The average age of the wild boar
population should be kept as high as possible (hunting: 80 % <one year old, 15 % 1-2 years old, 5 % >2 years old). In
the early stage of an epidemic, animals should not be disturbed in order to keep them in their habitat. In a later stage of
an epidemic, depopulation measures (hunting) should be started as soon as the incidence of disease has decreased with
a view to reducing the population density as much as possible.
Registration of all animals found dead or hunted is necessary. Annual screening (virology and serology) should also be
carried out in suspected areas. Virological examination of all animals found dead and virological and serological
monitoring of hunted animals should be performed.
The EU Commission has held a workshop dedicated to this topic (proceedings in press) and a working group of the
Scientific Committee on Animal Health and Animal Welfare will prepare a recommendation.
REFERENCES
1.
Anonymous (1980). EU Council Directive 80/217/EEC of 22 January 1980 introducing Community measures for
the control of Classical Swine Fever, last ammended 14 June 1993.
2.
Anonymous (1994). Report from the Scientific Veterinary Committee on Guidelines for a Classical Swine Fever
Emergency Vaccination Programme. Document VI/7389/94-EN, Commission of the European Communities.
3.
Anonymous (1996). Chapter 2.1.13. Classical swine fever (hog cholera). In: OIE Manual of Standards for
Diagnostic Tests and Vaccines, 3rd ed., OIE, Paris, 145-154.
4.
Anonymous (1997). Report of the Scientific Veterinary Committee (Adopted 17 September 1997): The use of
marker vaccines in the control of infectious deseases in pariticular, classical swine fever. Document VI/8119/97AL, Commission of the European Communites.
5.
Baker J.A. (1946). Serial passage of hog cholera virus in rabbits. Proc. Soc. Exp. Biol. Med., 63, 183-187.
6.
Cay B., Chappuis G., Coulibaly C.O.Z., Dinter Z., Edwards S., Greiser-Wilke I., Gunn M., Have P., Hess G.,
Juntti N., Liess B., Mateo A., McHugh P., Moennig V., Nettleton P. & Wensvoort G. (1989). Comparative
analysis of monoclonal antibodies against pestiviruses: report of an international workshop. Vet. Microbiol., 20,
123-129.
7.
Depner K.R., Müller A., Gruber A., Rodriguez A., Bickhardt K. & Liess B. (1995). Classical swine fever in wild
boar (Sus scrofa) - experimental infections and viral persistence. Dtsch., Tierarztl. Wochenschr., 102, 381-384.
8.
Elbers K., Tautz N., Becher P., Stoll D., Rümenapf T. & Thiel H.J. (1996). Processing in the pestivirus E2-NS2
region: identification of proteins p7 and E2p7. J. Virol., 70, 4131-4135.
9.
Hofmann M.A., Brechtbühl K. & Stäuber N. (1994). Rapid characterization of new pestivirus strains by direct
sequencing of PCR-amplified cDNA from the 5' non-coding region. Arch. Virol., 139, 217-219.
- 300 -
Conf. OIE 1998
10. Hooft van Iddekinge B.J., de Wind N., Wensvoort G., Kimman T.G., Gielkens A.L. & Moormann R.J. (1996).
Comparison of the protective efficacy of recombinant pseudorabies viruses against psoeudorabies and classical
swine fever in pigs; influence of different promoters on gene expression and on protection. Vaccine, 14, 6-12.
11. Huck R.A. & Aston F.W. (1964). The 'carrier' sow in swine fever. Vet. Rec., 76, 1151-1154.
12. Koprowski H., James T.R. & Cox H.R. (1946). Propagation of hog cholera virus in rabbits. Proc. Soc. Exp. Biol.
Med., 63, 178-183.
13. Krüger H. (1958). Impfschäden nach Anwendung der Kristallviolett-Vakzine zur Bekämpfung der Schweinepest.
Monatsh. Veterinarmed., 13, 356-358.
14. Lowings P., Ibata G., Needham J. & Paton D. (1996). Classical swine fever diversity and evolution. J. Gen. Virol.,
77, 1311-1321.
15. Meyer H., Liess B., Hermanns W. & Trautwein G. (1980). Experimentelle, diaplazentare Infektion von
Schweinefeten mit dem Virus der Europäischen Schweinepest (ESP). Virologische und serologische
Untersuchungen in der postnatalen Phase. Fortschritte der Veterinärmedizin. Suppl. Zbl. Vet. Med., 30, 140-144.
16. Meyers G. & Thiel H.J. (1996). Molecular characterization of pestiviruses. Adv. Virus Res., 47, 53-118.
17. Meyers G., Thiel H.J. & Rümenapf T. (1996). Classical swine fever virus: recovery of infectious viruses from
cDNA constructs and generation of recombinant cytopathogenic defective interfering particles. J. Virol., 70, 15881595.
18. Moennig V. & Plagemann G.W. (1992). The pestiviruses. Adv. Virus Res., 41, 53-98.
19. Moormann R.J., van Gennip H.G., Miedema G.K., Hulst M.M. & van Rijn P.A. (1996). Infectious RNA
transcribed from an engineered full-length cDNA template of the genome of a pestivirus. J. Virol., 70, 763-770.
20. Ruggli N., Tratschin J.D., Mittelholzer C. & Hofmann M.A. (1996). Nucleotide sequence of classical swine fever
virus strain Alfort/187 and transcription of infectious RNA from stably cloned full-length cDNA. J. Virol., 70,
3478-3487.
21. Rümenapf T., Stark R., Meyers G. & Thiel H.J. (1991). Structural proteins of hog cholera virus expressed by
vaccinia virus: further characterization and induction of protective immunity. J. Virol., 65, 589-597.
22. Savi P., Torlone V. & Titoli F. (1965). Recherches sur la survie du virus de la peste porcine classique dans
certains produits de charcuterie. Bull. OIE, 63, 87-96.
23. Staubach C., Teuffert J. & Thulke H.H. (1997). Risk analysis and local spread mechanisms of classical swine
fever. Epid. Santé Animale, 31-32, 6121-6123.
24. Susa M., König M., Saalmüller A., Reddehase M.J. & Thiel H.J. (1992). Pathogenesis of classical swine fever: Blymphocyte deficiency caused by hog cholera virus. J. Virol., 66, 1171-1175.
25. Van Oirschot J.T. (1992). Hog cholera. In: Diseases of swine, 7th ed., Leman et al., (eds). Iowa State University
Press, Iowa, 274-285.
26. Van Oirschot J.T. & Terpstra C.A. (1977). A congenital persistant swine fever infection. I. Clincal and virological
observations. II. Immue response to swine fever virus and unrelated antigens. Vet. Microbiol., 2, 121-142.
27. Van Rijn P.A., Bossers A., Wensvoort G. & Moormann R.J. (1996). Classical swine fever virus (CSFV) envelope
glycoprotein E2 containing one structural antigenic unit protects pigs from lethal CSFV challenge. J. Gen. Virol.,
77, 2737-2745.
28. Van Zijl M., Wensvoort G., de Kluyver E., Hulst M., van der Gulden H., Gielkens A., Berns A. & Moormann R.
(1991). Live attenuated pseudorabies virus expressing envelope glycoprotein E1 of hog cholera virus protects
swine against both pseudorabies and hog cholera. J. Virol., 65, 2761-2765.
- 301 -
Conf. OIE 1998
29. Wengler G. (1991). Family Flaviviridae. In: Classification and nomenclature of viruses. Fifth report of the
International Committee on Taxonomy of Viruses. Francki R.I.B., Fauquet C.M., Knudson D.L. & Brown F. (eds).
Springer Verlag, Berlin, 223-233.
Additional reading:
1.
Anonymous (1998). Untersuchungen zu Vorkommen, Ausbreitung und Bekämpfung der klassischen
Schweinepest (KSP) in Deutschland 1993-1995. Abschlußbericht zum Forschungsprojekt 96HS022, Institute of
Virology, Hannover Veterinary School, Buenteweg 17, D-30559 Hannover, Germany.
2.
Thiel H.J., Plagemann G.W. & Moennig V. (1996). Pestiviruses. In: Fiels Virology, 3rd ed., Fields B.N., Knipe
D.M., Howley P.M. et al. (eds.). Lippincott-Raven Publishers, Philadelphia, 1059-1073.
- 302 -
