Copper Telecom Cables

ISO 9001 : 2000 CERTIFIED
BY AFAQ No. QUAL/ 1997 / 7034 a
Quality • Reliability • Innovation
COPPER TELECOMMUNICATION CABLES

COPPER
TELECOMMUNICATION CABLES

NOTICE
INTRODUCTION
QUALITY ASSURANCE
RECOMMENDED ORDERING PARAMETERS
OUR TYPE AND CODE DESIGNATION
DUCT, UNDERGROUND NETWORK CABLES USED IN
FEEDER AND DISTRIBUTION
6.1- PE insulated, Petroleum jelly filled, PE sheathed
6.2- PE insulated, PE sheathed
DIRECT BURIAL, UNDERGROUND NETWORK CABLES
USED IN FEEDER AND DISTRIBUTION
7.1- PE insulated, Petroleum jelly filled, double steel tape armoured, PE sheathed
7.2- PE insulated, double steel tape armoured, PE sheathed
FIGURE 8 AERIAL NETWORK CABLES USED IN DISTRIBUTION
8.1 - PE insulated, Petroleum jelly filled, PE sheathed, with steel
messenger
8.2 - PE insulated, PE sheathed, with steel messenger
8.3 - PE insulated, Petroleum jelly filled, double steel tape armoured,
PE sheathed, with steel messenger
8.4 - PE insulated, double steel tape armoured, PE sheathed, with steel
messenger
INDOOR USE TELEPHONE CABLES, PVC INSULATED
AND PVC SHEATHED
JUMPER WIRE
DROP WIRE
ANNEX A- INDENTIFICATION OF CONDUCTORS AND UNITS
AND CABLE CORE CONSTRUCTION OF
UNDERGROUND AND AERIAL NETWORK CABLES
ANNEX B - IDENTIFICATION OF CONDUCTORS OF
INDOOR USE TELEPHONE CABLE - LIBTEL
P a g e
1
2
3
3
4
6
6
9
1 2
1 2
1 5
1 8
1 8
2 1
2 4
2 7
3 0
3 2
3 3
3 4
3 6
1
2
3
4
5
6
7
8
9
10
11
CONTENTS

1
As this catalogue is not intended to cover all of LIBAN CABLES S A L possibilities in
Copper Telephone Cables manufacturing, the hereafter listing of the types of cables is not
restrictive but only indicative of the main and most current types we manufacture.
On the other hand, our specification sheets are inspired mainly from International
Electrotechnical Commission Specifications (IEC) only in order to conform with the
sustained trend, noticed both regionally and worldwide, towards these same IEC
supposed to inspire any further standardization approaches.
That is why, while consulting this brochure, it is important to keep in mind that:
- any combination or change of the constructional details mentioned in hereafter
chapter 5 remains feasible, on base of special conception development, matching
any special or different specifications,
- we can offer additional possibilities and alternatives like for example:
- Pair, quad, and other basic formations
- Unit or concentric stranding
- Comparted construction (ex: MIC cables)
- our production encompasses all telecom cables of low, high or special mutual
capacitance and conductor gauges ≥ 0.4 mm.
F i n a l l y, and within our policy of constant improvement, we reserve the right to alter any
part of the information contained in this publication without incurring any obligation. In
all cases this brochure being only indicatve, and unless expressly agreed upon, it cannot
be considered by any mean as contractual document.
1NOTICE
