C-IPC-171-eng

C-IPC 171
C-DIAS IPC
with AMD Fusion G-T56N
Date of creation: 27.07.2017
Version date: 20.11.2023
Article number: 01-450-171-E

Publisher: SIGMATEK GmbH & Co KG
A-5112 Lamprechtshausen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
WWW.SIGMATEK-AUTOMATION.COM
Copyright © 2017
SIGMATEK GmbH & Co KG
Translation from German
All rights reserved. No part of this work may be reproduced, edited using an electronic system, duplicated or dis-
tributed in any form (print, photocopy, microfilm or in any other process) without the express permission.
We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi-
ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through
use of this handbook.

C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171
20.11.2023 Page 1
C-DIAS IPC with AMD Fusion G-T56N C-IPC 171
Compact DIAS
Industrial
Personal
Computer
The C-IPC is a C-DIAS industrial PC with
an AMD Fusion processor. A 7-segment
display and 3 status LEDs provide infor-
mation on the actual status of the CPU.
A CompactFlash card can be used as
program memory. The C-IPC also has an
VGA interface for a display and a USB
V1.1 interface. In addition, an expansion
card with further interface connections is
available.
Compatibility
Completely PC-compatible. The C-IPC works with a standard PC BIOS; no SIGMATEK-
specific BIOS is therefore needed. LASAL is provided as the operating system.

C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N
Page 2 20.11.2023
Contents
1 Technical Data ........................................................................ 4
1.1 Performance Data ......................................................................... 4
1.2 Standard Configuration ................................................................ 5
1.3 Electrical Requirements ............................................................... 5
1.4 Miscellaneous ............................................................................... 6
1.5 Environmental Conditions ........................................................... 6
1.6 Xilinx Version ................................................................................ 7
1.7 Post Codes .................................................................................... 7
2 Mechanical Dimensions ......................................................... 8
3 Connector Layout ................................................................... 9
3.1 Connector Layout ....................................................................... 10
3.2 Applicable Connectors ............................................................... 13
3.3 Bottom Connectors .................................................................... 14
4 Status Displays ......................................................................15
5 Setting C-IPC Parameters with the SET Button (under
LASAL operating system only) .............................................16
6 Design Layout ........................................................................19
6.1 Exchanging the CompactFlash Card ........................................ 22
6.2 Storage Media ............................................................................. 23
6.3 Exchanging the Battery .............................................................. 24

C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171
20.11.2023 Page 3
6.4 CAN Bus Termination ................................................................. 25
6.5 RS485 ........................................................................................... 26
6.6 USB Interface Connections ....................................................... 27
6.7 DIAS Bus Termination ................................................................ 27
6.8 The DIAS Bus Connection ......................................................... 27
6.9 Connecting DIAS Modules ......................................................... 29
7 Buffer Battery ........................................................................ 30
8 Cooling ................................................................................... 31
9 System Boot Checkpoints .................................................... 31
10 Status and Error Messages .................................................. 32
