FITTINGS
4RS PRO Product Guide See our full range of products and additional technical information at: rspro.com
Stock No. Tube A B C L CH1 CH2 Pack
176-1276 4 1/8 6 13 20 10 3 10
176-1283 4 1/4 8 16 19.5 16 3 10
176-1275 4 M5 4 8 21 10 2 10
176-1277 6 1/8 6 13 23.5 13 4 10
176-1278 6 1/4 8 16 23.5 13 4 10
176-1284 6 3/8 9 20 25 13 4 10
176-1285 6 1/2 10 25 27 13 4 10
176-1282 6 M5 4 10 24.5 13 2 10
176-1279 8 1/8 6 13 25 14 5 10
176-1280 8 1/4 8 16 23 14 6 10
176-1281 8 3/8 9 20 24 14 6 10
176-1286 8 1/2 10 25 26.5 14 6 10
176-1764 8 M121.5 8 15 27.5 14 6 10
176-1761 10 1/4 8 16 30.5 17 6 10
176-1762 10 3/8 9 20 27.5 17 8 10
176-1768 10 1/2 10 25 27 17 8 10
176-1769 12 1/4 8 16 34.5 20 6 10
176-1763 12 3/8 9 20 34 20 8 10
176-1765 12 1/2 10 25 31 22 10 10
176-1766 14 3/8 9 20 35 21 10 10
176-1767 14 1/2 10 25 32 22 11 10
STRAIGHT MALE ADAPTOR (PARALLEL)
Features
Designed for arduous applications in packaging, automotive and production environments, RS PRO
push-in fittings contain a range of nickel plated brass connectors. Quick connection/disconnection
and metal robustness help make this range the icon of quality, reliability and endurance in the
pneumatic field.
Push-In Fittings
Push-In Fittings
Main advantages
• Quick connection and disconnection
• Full flow and vacuum resistance thanks
to shaped seals
• 3 threads available: BSPP, BSPT
(universal short) & metric
• Lighter and more compact
• Specific configurations to satisfy
advanced robotics applications
• Silicon free
Applications
• Robotics
• Automotive
• Textile, packaging, handling
• Compressed air circuits
• Industrial water
• Vacuum
CH2
B
CH1
A
C
L

FITTINGS
5RS PRO Product Guide See our full range of products and additional technical information at: rspro.com
Stock No. Tube A B L CH Pack
176-1287 4 1/8 8.5 24 13 10
176-1294 4 1/4 11 27.5 16 10
176-1293 4 M5 5.5 21 11 10
176-1288 6 1/8 8.5 26 13 10
176-1290 6 1/4 11 29.5 16 10
176-1291 8 1/8 8.5 27 15 10
176-1292 8 1/4 11 29.5 17 10
176-1295 8 3/8 12 32 19 10
176-1770 10 1/4 11 32 18 10
176-1771 10 3/8 12 33.5 19 10
176-1772 10 1/2 15 39 24 10
176-1773 12 3/8 12 36 21 10
176-1774 12 1/2 15 41 24 10
STRAIGHT FEMALE ADAPTOR
Push-In Fittings
A
B
L
CH
