INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) ER-0109/1996 Page: 1 ISO 9001 AUTOCLAVES AUTOMATICOS PARA ESTERILIZACIÓN A VAPOR CON SISTEMA PREVACUUM AUTOMATIC AUTOCLAVES FOR STEAM STERILIZATION AUTESTER ST DRY PV-II 30 AUTESTER ST DRY PV-II 50 AUTESTER ST DRY PV-II 75 J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es 4002514 4002515 4002425 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 2 Índice 1 Seguridad ................................................................................................................................................. 4 2.1 Iconos de seguridad .................................................................................................................................................................. 4 2.2 Riesgos a los que está sometido el operador: ............................................................................................................................. 4 2.3 Cualificación del personal .......................................................................................................................................................... 4 2 Información general ................................................................................................................................. 5 3 Especificaciones técnicas .......................................................................................................................... 5 4 Lista de embalaje y accesorios .................................................................................................................. 6 4.1 Contenido estandar del paquete ................................................................................................................................................. 6 4.2 Accesorios ................................................................................................................................................................................ 6 5 Introducción ............................................................................................................................................. 7 5.1 Definiciones: ............................................................................................................................................................................. 7 5.1.2 Esterilización .......................................................................................................................................................................... 7 5.1.3 Desinfección .......................................................................................................................................................................... 7 5.1.4 Medios de cultivo ................................................................................................................................................................... 7 5.1.5 Priones .................................................................................................................................................................................. 7 5.1.6 Purgado ................................................................................................................................................................................ 7 5.1.7 Vapor saturado ...................................................................................................................................................................... 7 5.1.8 Purgado atmosférico .............................................................................................................................................................. 7 5.1.9 Purgado por vacío fraccionado ................................................................................................................................................ 7 5.1.10 Test de Bowie Dick ............................................................................................................................................................... 7 5.1.11 Test de vacío ........................................................................................................................................................................ 7 6 Descripción del equipo .............................................................................................................................. 8 6.1 6.2 6.3 6.4 6.5 6.6 6.7 Equipamiento ........................................................................................................................................................................... 8 Prestaciones ............................................................................................................................................................................. 9 Modos y rangos de funcionamiento ............................................................................................................................................ 9 Programas de usuario ............................................................................................................................................................... 9 Programas de test ..................................................................................................................................................................... 9 Panel de mandos .................................................................................................................................................................... 10 Localización de los elementos .................................................................................................................................................. 10 7 Instalación .............................................................................................................................................. 11 8 Funcionamiento ...................................................................................................................................... 12 9 Diagrama general de menús ................................................................................................................... 13 9.1 Selección de Programa ............................................................................................................................................................ 9.2 Modificación de Programa ........................................................................................................................................................ 9.3 Modificación del Idioma ........................................................................................................................................................... 9.4 Configuración Unidades ........................................................................................................................................................... 9.5 Configuración Impresora ......................................................................................................................................................... 9.6 Configuración entrada agua externa ......................................................................................................................................... 9.7 Configuración sonda exterior ................................................................................................................................................... 9.8 Configuración reloj .................................................................................................................................................................. 9.9 Ensayo test vacío .................................................................................................................................................................... 9.10 Ensayo test Bowie-Dick .......................................................................................................................................................... 10 11 12 13 14 15 16 14 15 16 17 18 19 20 22 23 24 Alarmas ................................................................................................................................................ 25 Recomendaciones para lograr una perfecta esterilización .................................................................... 26 Sistemas de protección ......................................................................................................................... 27 Calibraciones ........................................................................................................................................ 28 Mantenimiento ..................................................................................................................................... 29 Recambios ............................................................................................................................................ 29 Esquemas ............................................................................................................................................. 30 16.1 Esquemas eléctrico y de potencia ........................................................................................................................................... 30 16.2 Esquema hidráulico ............................................................................................................................................................... 32 17 Instruciones complementarias ............................................................................................................. 33 17.1 17.2 17.3 17.4 17.5 17.6 17.7 17.8 Instalación: ........................................................................................................................................................................... Legalización de la instalación: ................................................................................................................................................ Revisiones anuales: ............................................................................................................................................................... Pruebas hidráulicas periódicas: ............................................................................................................................................... Apertura y cierre de la puerta de carga y descarga: ................................................................................................................. Precauciones durante la utilización: ........................................................................................................................................ Mantenimiento ...................................................................................................................................................................... Características del diseño determinantes para la vida del equipo .............................................................................................. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es 33 33 33 33 33 34 34 34 Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 3 Table of contens 1 Safety ..................................................................................................................................................... 36 2.1 Safety Icons ........................................................................................................................................................................... 36 2.2 Risks that the operator can be subjected to: ............................................................................................................................. 36 2.3 Qualified users ........................................................................................................................................................................ 36 2 General information ................................................................................................................................ 37 3 Technical specifications. ......................................................................................................................... 37 4 Contents list and accessories .................................................................................................................. 38 4.1 Standard contents ................................................................................................................................................................... 38 4.2 Accessories ............................................................................................................................................................................. 38 5 Introduction ........................................................................................................................................... 39 5.1 Definitions: ............................................................................................................................................................................. 5.1.2 Esterilization ........................................................................................................................................................................ 5.1.3 Disinfetión ........................................................................................................................................................................... 5.1.4 Culture media ...................................................................................................................................................................... 5.1.5 Prions .................................................................................................................................................................................. 5.1.6 Purge .................................................................................................................................................................................. 5.1.7 Saturated vapour ................................................................................................................................................................. 5.1.8 Atmospheric purge ............................................................................................................................................................... 5.1.9 Pulsed vacuum purge ........................................................................................................................................................... 5.1.10 Bowie Dick test .................................................................................................................................................................. 5.1.11 Vacuum test ....................................................................................................................................................................... 39 39 39 39 39 39 39 39 39 39 39 6.1 6.2 6.3 6.4 6.5 6.6 6.7 Equipment .............................................................................................................................................................................. Features ................................................................................................................................................................................. Operating mode range ............................................................................................................................................................ User programs ........................................................................................................................................................................ Test programs ........................................................................................................................................................................ Control panels ........................................................................................................................................................................ Manual function control location ............................................................................................................................................... 40 41 41 41 41 41 42 9.1 Selection promgam ................................................................................................................................................................. 9.2 To modify programs ................................................................................................................................................................ 9.3 Change language .................................................................................................................................................................... 9.4 Confifure units ºC-ºF ............................................................................................................................................................... 9.5 Configure printer option .......................................................................................................................................................... 9.6 Configure external water source .............................................................................................................................................. 9.7 Configure external probe ......................................................................................................................................................... 9.8 Configure time ........................................................................................................................................................................ 9.9 Configure vacuum test ............................................................................................................................................................ 9.10Configure Bowie-Dick test ....................................................................................................................................................... 46 47 48 48 50 51 52 54 55 56 6 Equipment description ............................................................................................................................ 40 7 Installation ............................................................................................................................................. 42 8 Operation ................................................................................................................................................ 44 9 General Diagram and menu .................................................................................................................... 45 10 11 12 13 14 15 Alarms and errors ................................................................................................................................. 57 Recomendation to achieve a perfect sterilisation ................................................................................. 58 Protection system ................................................................................................................................. 59 Calibration ............................................................................................................................................ 60 Maintenance ......................................................................................................................................... 61 Schematic ............................................................................................................................................. 62 15.1 Power circuit schematic ......................................................................................................................................................... 62 15.2 Hydraulic schematic .............................................................................................................................................................. 64 17 Complemetary instructions ................................................................................................................... 65 17.1 17.2 17.3 17.4 17.5 17.6 17.7 17.8 Installation: .......................................................................................................................................................................... Legalization of the installation: ............................................................................................................................................... Annual review ....................................................................................................................................................................... Periodic hidraulic tests: .......................................................................................................................................................... Aperture and closing of the loading and unloading lid: ............................................................................................................. Precautionary measures during the use: ................................................................................................................................. Maintenance ......................................................................................................................................................................... Desing features which are determinant to the equipment life ................................................................................................... J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es 65 65 65 65 65 66 66 66 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 4 1 Seguridad El equipo incluye las medidas de seguridad adecuadas. A lo largo de este manual se indican las situaciones de riesgo que deben respetarse. 2.1 Iconos de seguridad Identifican las situaciones de riesgo y las medidas de seguridad que deben tomarse. Los íconos hacen referencia al párrafo marcado con la línea gris. Riesgo de peligro Riesgo de peligro. Respetar las instrucciones indicadas para realizar la operación descrita. Riesgo eléctrico Riesgo de accidente eléctrico al acceder a las zonas indicadas con esta señal o en realizar las operaciones indicadas en este manual acompañadas de este icono. Respetar las instrucciones indicadas para realizar la operación descrita. Riesgo de quemaduras por contacto con zonas a temperatura elevada. La temperatura en la zona indicada con este icono puede exceder los 60ºC. Utilizar guantes antitérmicos para realizar la operación descrita. Respetar las instrucciones indicadas para realizar la operación descrita. Información importante • Información importante para obtener buenos resultados o para un funcionamiento óptimo del equipo. • Información importante para alargar la vida del equipo o evitar la degradación de alguno de sus componentes. 2.2 Riesgos a los que está sometido el operador: • Posibilidad de tocar piezas a una temperatura superior a 60ºC.. • Posible exposición a vapores. • Riesgo eléctrico. 2.3 Cualificación del personal Este equipo sólo puede ser utilizado por personal que ha sido cualificado adecuadamente. Este equipo sólo puede ser utilizado por personal que ha leido y comprendido estas instrucciones o ha sido cualificado adecuadamente en el funcionamiento de este equipo. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 5 2 Información general 2.1 Manipular el paquete con cuidado. Desembalarlo y comprobar que el contenido coincide con lo indicado en el apartado de la “Lista de embalaje”. Si se observa algún componente dañado o la ausencia de alguno avisar rápidamente al distribuidor. 2.2 No instalar ni utilizar el equipo sin leer, previamente, este manual de instrucciones. 2.3 Estas instrucciones forman parte inseparable del aparato y deben estar disponibles a todos los usuarios del equipo 2.4 Cualquier duda puede ser aclarada contactando con el servicio técnico de J.P. SELECTA, s.a. 2.5 ¡ATENCIÓN! NO SE ADMITIRÁ NINGUNA MÁQUINA PARA REPARAR QUE NO ESTÉ DEBIDAMENTE LIMPIA Y DESINFECTADA. 2.6 Toda modificación, eliminación o falta de mantenimiento de cualquier dispositivo de la máquina, transgrede la directiva de utilización 89/655/CEE y el fabricante no se hace responsable de los daños que pudieran derivarse. 2.7 No utilizar el equipo con fluidos que puedan desprender vapores o formar mezclas explosivas o inflamables. NO SE PUEDE ABRIR LA TAPA DEL AUTOCLAVE SI LA MÁQUINA NO ESTÁ CONECTADA A LA RED Y EL INTERRUPTOR PRINCIPAL ILUMINADO. SIN ESTAS CONDICIONES NO FORZAR LA PALANCA DE APERTURA 3 Especificaciones técnicas Tensión de alimentación 115/230V 50/60 Hz según se indique en la placa de características de la máquina. Código Code Secado Drying 4002514 4002515 Sí Yes 4002425 J.P. SELECTA s.a. Medidas útiles (cm) Capacidad (litros) Chamber dimensions (cm) Capacity (litres) Alto Ø Height Medidas exteriores (cm) Overall dimensions (cm) Alto Height Ancho Length Fondo Width 30 30 40 117 48 62 50 30 70 117 48 62 75 40 60 107 58 72 Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Rango (ºC) Range (ºC) 105 a/to 134 Potencia (W) Power (W) Peso (kg) Weight (kg) 2800 90 3000 108 3600 136 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 6 4 Lista de embalaje y accesorios 4.1 Contenido estandar del paquete El equipo estándard consta de los siguientes componentes: Descripción 5600-5601 Description Código/Code Autester ST DRY PV-II Autester ST DRY PV-II Bandeja Shelf 4002514 4002515 Racord vaciado Empying racord 34100 Manual de instruciones Instruction manual 80206 4002425 5601 5600 4.2 Accesorios 34100 • Impresora térmica de papel contínnuo con indicación de temperatura, presión, tiempo, modalidad y estado. Código 4002417 • Sonda para lecturas de temperatura interior de la caldera, con dos aplicaciones (Código 4001219) : Toma valores para registrador o termómetro Uso en programas de líquidos o en el interior de esterilización de material embalado. • Cestillos en plancha perforada en acero AISI 316 4001219 Código cestillo Basket code • 1000495 1000496 • 1002418 J.P. SELECTA s.a. Para autoclave cod. Capacidad cestillos To autoclave code Number of baskets Ø Altura/Height 1000495 28 20 4002514 2 1000495 28 20 4002515 3 1000496 38 28 4002425 2 Bastidores en alambre de acero inoxidable AISI 316 - Código: 1001217 Bastidor 4 compartimentos para cestillo 1000495 - Código: 1001218 Bastidor 6 compartimentos para cestillo 1000496 1002419 1002418 Medidas (cm) Dimensions (cm) Tambores de esterilización Alto Para autoclave cod. To autoclave code Capacidad tambores Drums capacity 28 18 4002514 2 1002418 28 18 4002515 3 1002419 35 27 4002425 2 Código Code Ø 1002418 (cm) 1002419 Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 7 5 Introducción Los autoclaves Autester ST DRY PV II son equipos versátiles destinados a un àmplio espectro de aplicaciones en los campos, sanitàrios, procesos industriales y el control de calidad. Estos autoclaves permiten procesos de esterilización de sólidos con y sin embalaje, liquidos, medios de cultivo y priones. También permiten ciclos de desinfección así como secado. 5.1 Definiciones: 5.1.2 Esterilización Se entiende por esterilizar la destrución de o eliminación de toda forma de vida microbiana, incluyendo esporas- presente en objetos inanimados. 5.1.3 Desinfección Se entiende por desinfección el proceso de destrución de agentes infecciosos. Se realiza a temperatura més baja que la esterilización. La Desinfección consigue eliminar sólo algunas formas vegetativas. 5.1.4 Medios de cultivo Material nutritivo en el que se pueden recuperar, multiplicar y aislar los microorganismos, así como efectuar pruebas de suceptivilidad. Generalmente se presentan desecados en forma de polvo fino o granular, pero también pueden presentarse hidratados y preparados. No deben utilizarse sin antes ser esterilizados. 5.1.5 Priones Los priones son partículas acelulares, patógenas y transmisibles. Se caracterizan por producir enfermedades que afectan al sistema nervioso central (SNC). Los priones no son seres vivos, son partículas exclusivamente proteicas sin ácido nucleico. Su acción patógena consiste en ser una forma modificada de una proteína natural existente en el organismo que al entrar en contacto con las proteínas originales las induce a adoptar la forma del prión, que suele ser una forma anormal y disfuncional, todo ello en una acción en cadena que acaba por destruir la operatividad de todas las proteínas sensibles al prión. 5.1.6 Purgado El purgado es el ciclo mediante el cual se elimina el aire del interior de la caldera con el fin de conseguir vapor saturado. 5.1.7 Vapor saturado Vapor de agua a una temperatura correspondiente al punto de ebullición del liquido origen. 5.1.8 Purgado atmosférico En el purgado atmosférico el aire sale al exterior de forma gravimètrica, impusado por el vapor durante un tiempo determinado. 5.1.9 Purgado por vacío fraccionado El purgado por vacío fraccionado combina el calentamiento de la caldera con con la extracción de aire mediante bomba de vacío. Durante el ciclo de purgado la caldera puede alcanzar dos veces o tres veces (según modo de trabajo configurado) un alto nivel de vacío. La fiabilidad del pugado es mayor que con el purgado atmostérico. 5.1.10 Test de Bowie Dick El ensayo de Bowie Dick sirve para verificar el funcionamiento de los esterilizadores de vapor de agua aplicable a los productos envueltos y cargas porosas. 5.1.11 Test de vacío Test destinado a verificar el funcionamiento de la bomba de vacío y la estanqueidad de la la cámara y el circuito hidráulico durante un tiempo determinado. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 8 6 Descripción del equipo Los autoclaves Autester ST DRY PV II de 30, 50 y 75 litros pertenecen a una serie de autoclaves a vapor saturado que se distinguen por las siguientes caraterísticas: 1. Sistema de cierre radial de 6 puntos. 2. Generador de vapor externo al depósito principal. 3. Multiples modalidades de funcionamiento totalmente configurables por el usuario. 4. Menus de operación totalmente intuitivos 5. Preparadas para funcionar con dos sondas. La instalación de la segunda sonda (cód. 4001219) debe ser realizada en fábrica. 6. Conexión externa RS-232 6.1 Equipamiento - Sistema de seguridad: Válvula de seguridad Presostato de máxima Termostato de máxima Detector de tapa bien cerrada Envolvente de protección térmica J.P. SELECTA s.a. - Generador de vapor externo al depósito principal - Caldera y tapa en acero inoxidable 18/8/2 - Mueble exterior en acero inoxidable - Filtro de toma de agua exterior - Válvula manual de desvaporización - Válvula selectora de drenaje (exterior/tanque) - Tetina salida condensados bomba de vacío - Rácord toma de agua exterior - Tanque interior de 10 litros - Tetina vaciado al exterior del agua del tanque Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 9 6.2 Prestaciones - Temperatuda de esterilización desde 105ºC hasta 134ºC Tiempo de esterilización desde 3 minutos hasta 59 minutos Cuatro modalidades de funcionamiento 6.3 Modos y rangos de funcionamiento Sin sonda exterior Con sonda exterior Sólidos purgado atmosférico 105-134 105-130 Sólidos dos fracciones 115-134 115-130 Sólidos tres fracciones 115-134 115-130 Líquidos purgado atmosférico 105-134 105-130 6.4 Programas de usuario Los autoclaves Autester ST DRY PV II tienen 10 programas de trabajo preestablecidos que pueden ser modificados en función de las necesitades del usuario. ºC Tiempo esterilización Tiempo secado Fracciones 0 Intrumental NO embalado 134 4 10 2 1 Intrumental embalado 134 12 30 3 2 Priones 134 20 20 3 3 Delicado No embalado 121 15 15 2 4 Delicado embalado 121 30 30 3 5 Instrumental 126 12 25 3 6 Desinfección 105 25 15 1 7 Líquidos 121 30 - 1 8 Sólidos 121 15 30 1 9 Sólidos 134 4 30 1 1. Purgado atmosférico 2. Purgado con dos fracciones de vacío 3. Purgado con tres fracciones de vacío 6.5 Programas de test Los autoclaves Autester ST DRY PV II tienen 2 programas de test: - Test de Bowie Dick Test de Vacío Test Bowie Dick Test Vacío J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es 134ºC - 3' 30" - 0,7 bar 5' / 8' Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 10 6.6 Panel de mandos 5 1. 2. 3. 4. 5. 2 1 Display LCD indicador de parámetros Selector monomando Led indicador de marcha Pulsador marcha / paro Impresor (opcional) 3 4 6.7 Localización de los elementos 6 6. 7. Maneta cierre tapa Interruptor general 8. Entrada de agua depósito 9. 10. Conector RS232 (puerto serie) Conector sonda externa (Pt100) 11. 12. 13. 14. 15. 16. 17. 18. Válvula de seguridad Válvula de vaciado vapor Entrada de agua externa Filtro de aireación Termostatos de máxima Salida agua tanque Salida condensados Válvula de drenaje 7 8 9 10 11 12 13 14 15 16 17 18 J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 11 7 Instalación 7.1 Situar el autoclave cerca de una toma de corriente adecuado al consumo de la máquina. 7.2 El autoclave se asentará sobre una superficie plana, horizontal y estable, dejando un espacio libre de 10cm alrededor de la máquina. 7.3 Inmovilizar el autoclave,ajustándolo al suelo, mediante los topes situados en la parte anterior del aparato, previstos para tal efecto. 7.4 Fijar un tubo en la tetina para recoger los condensados que se forman durante las fases en que funciona la bomba de vacío. No colocar el recipiente de recogida a un nivel superior al de la tetina. 7.5 ENTRADA EXTERIOR DE AGUA: 7.5.1 El autoclave se puede llenar a través de la red exterior mediante una toma de 3/4" tal y como se indica en la foto. La presión de suministro nunca debe ser superior a 2bar. Esta forma de llenado debe de configurarse. Ver apartado 9.6. ATENCIÓN No usar la opción de vaciado exterior sin antes haber conectado una manguera de presión. Fijar la manguera de manera que no pueda moverse por efecto de la presión al final del ciclo. No sujetar la manguera con las manos, puede sufrir quemaduras. 7.6 SELECCIÓN DEL SISTEMA DE DRENAJE: J.P. SELECTA s.a. 7.6.1 Con la válvula selectora indicada, si se quiere recuperar el agua al final de cada proceso de esterilizado, colocar el mando de dicha válvula señalándolo hacia el interior de la máquina. 7.6.2 Si se quiere expulsar el agua al exterior, al final de cada proceso de esterilizado, colocar el mando de dicha válvula en dirección al exterior. Fijar una manguera en la tetina de salida de la válvula y fijar también el otro extremo a un recipiente o desague, procurando NO OBSTRUIR EL TUBO. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 12 ¡ATENCIÓN! La salida de vapor por la válvula (12) y la salida de vapor y agua por la tetina de la válvula (18) es a PRESIÓN y a TEMPERATURA ELEVADA. Tome todas las precauciones para evitar GRAVES QUEMADURAS. NUNCA SUJETE LA MANGUERA COLOCADA EN LA TETINA DE LA VÁLVULA (18) CON LA MANO YA QUE PODRÍA CAUSAR QUEMADURAS IMPORTANTES. 8 Funcionamiento 8 NO SE PUEDE ABRIR LA TAPA DEL AUTOCLAVE SI LA MÁQUINA NO ESTÁ CONECTADA A LA RED Y EL INTERRUPTOR PRINCIPAL ILUMINADO. SIN ESTAS CONDICIONES NO FORZAR LA PALANCA DE APERTURA 8.1 PUESTA EN MARCHA Poner en marcha mediante el interruptor general(7). Llenar el depósito (8) de agua con unos 8 litros aproximadamente. Comprobar que esté cerrada la válvula de vaciado vapor(12). Colocar la bandeja en el fondo de la caldera. Colocar el material a esterilizar. Cerrar la tapa. Nota informativa En los procesos en que la máquina esté fría antes de su puesta en marcha necesitaremos un precalentamiento de entre 10 y 15 minutos. Precalentamiento: Enchufar, pulsar el interruptor general y dejar la máquina encendida durante los 10-15 minutos. 8.2 PROGRAMACIÓN Una vez pulsado el interruptor general (7), el display mostrará durante unos segundos un mensaje de inicio: Marca - Versión del Software - Modelo A continuación aparecerá el mensaje por defecto que corresponderá al último programa utilizado. Si el programa corresponde a la operación deseada el equipo se puede poner en marcha mediante el pulsador marcha/paro; se encenderá el led (3). Para elegir las diferentes operaciones que dispone el equipo para su utilización vea el punto 8, diagrama general de menús, donde podrá cambiar todos l os parámetros necesarios para su óptimo funcionamiento J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 Marzo/07 (It can be modified without notice) Page: 13 9 Diagrama general de menús INSTRUCTION MANUAL CODE 80206 REV A J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 14 9.1 Selección de Programa Si el programa no corresponde a la selección deseada pulsar el botón monomando, apareciendo en la pantalla «PROGRAMS». Pulsar nuevamente. Girar el botón monomando hasta encontrar el programa deseado. Una vez encontrado el programa pulsar el botón monomando y aparecerá «Select», pulsar de nuevo para validar. Aparecerá durante unos segundos la pantalla de confrimación «SELECTED» Finalmente aparecerá la pantalla por defecto con el programa seleccionado. Pulsar el pulsador de marcha/paro, se encenderá el LED y el equipo se pondrá en marcha. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 15 9.2 Modificación de Programa Si no encontramos el programa deseado podemos adaptar uno a medida ciñéndonos siempre a los parámetros que nos permite el equipo. A través del menú «PROGRAMS» pulsamos el monomando para acceder a los diferentes programas. Girando el botón podemos colocarnos en el número de programa que mas se adapta a nuestras necesidades y para poderlo modificar. Pulsando el botón monomando aparecerá «SELECT». Giramos el botón para que aparezca «MODIFY», volvemos a pulsar el botón, aparecerá en pantalla el programa que queremos modificar. Una vez modificado el programa pulsamos el botón y aparecerá «SELECT», pulsamos nuevamente para validar, aparecerá durante unos segundos la pantalla «SELECTED». Finalmente aparecerá la pantalla por defecto con el programa seleccionado. Pulsar el pulsador de marcha/paro, se encenderá el LED y el equipo se pondrá en marcha. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 16 9.3 Modificación del Idioma Para poder cambiar el idioma pulsar el monomando, aparecerá el menú «PROGRAMS». Girar el monomando hasta que aparezca en pantalla el menú «CONFIGURATION»; pulsar de nuevo el monomando y aparecerá el submenú «LANGUAGE». Pulsar el botón y en pantalla aparecerá el idioma que esté memorizado por defecto. Girar hasta visualizar el idioma deseado y pulsar el botón para validarlo; aparecerá durante unos segundos en pantalla «SELECTED». Volver a girar el botón hasta que aparezca «EXIT». Pulsar el botón «CONFIGURATION». monomando, aparecerá en pantal la Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con el idioma seleccionado. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 17 9.4 Configuración Unidades En caso de querer cambiar la unidad pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS». Girar el botón monomando hasta que aparezca en pantalla «CONFIGURATION». Pulsar el botón monomando y aparecerá en pantalla «LANGUAGE». Girar el botón hasta que aparezca el submenú «UNITS». Pulsar el botón monomando y cambiará de grados Celsius a Farenheit. Volver a girar el botón hasta que aparezca «EXIT». Pulsar el botón «CONFIGURATION». monomando, aparecerá en pantal la Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con la unidad seleccionada. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 18 9.5 Configuración Impresora Para poder activar y configurar la impresora pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS» Girar el botón monomando hasta que aparezca en pantalla «CONFIGURATION». Pulsar el botón monomando y aparecerá en pantalla «LANGUAGE». Girar el botón hasta que aparezca el submenú «PRINTER». Pulsar el botón monomando, aparecerá en pantalla «PRINTER STATUS». Volver a pulsar el botón para activar la impresora «ON». Girar el botón monomando y aparecerá en pantalla «PRINT INTERVAL». Pulsar el botón para cambiar el tiempo en minutos. Girar el botón monomando y aparecerá en pantalla «PRESS BUTTON». En caso de sustitución del papel se debe pulsar el botón para que el papel corra. Girar el botón monomando y hasta que aparezca en pantalla «EXIT». Pulsar el botón «CONFIGURATION». monomando, aparecerá en pantal la Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con la unidad seleccionada. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 19 9.6 Configuración entrada agua externa En caso de querer suministrar agua al autoclave con una toma externa configurar la misma de la siguiente manera: Pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS». Girar el botón monomando hasta que aparezca en pantalla «CONFIGURATION». Pulsar el botón monomando y aparecerá en pantalla «LANGUAGE». Girar el botón hasta que aparezca el submenú «EXTERNAL WATER». J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 20 volver a pulsar el botón para activar la válvua «ON». Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón monomando hasta que aparezca en pantalla el menú «CONFIGURATION». Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con la unidad seleccionada. 9.7 Configuración sonda exterior En caso de querer colocar un sonda externa configurar la misma de la siguiente manera: Pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS». Girar el botón monomando hasta que aparezca en pantalla «CONFIGURATION». J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 21 Pulsar el botón monomando y aparecerá en pantalla «LANGUAGE». Girar el botón hasta que aparezca el submenú «EXTERNAL PROBE». Pulsar el botón para activar la sonda exterior «ON». Girar el botón hasta que en la pantalla aparezca «EXIT» Pulsar el botón hasta que aparezca «CONFIGURATION». Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con la unidad seleccionada. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 22 9.8 Configuración reloj Para poder configurar el reloj es necesario pulsar el botón monomando, aparecerá en pantalla el menú «PROGRAMS». Girar el botón y aparecerá en pantalla «CONFIGURATION». Pulsar el botón monomando y aparecerá en pantalla «LANGUAGE». Girar el botón hasta que aparezca el submenú «CLOCK». Pulsar el botón hasta que aparezca en pantalla «CHANGE DATE». Volver a pulsar el botón y aparecerá la pantalla para poder modifcar los parámetros del reloj. Una vez configurados los parámetros del reloj pulsaremos el botón monomando y aparecerá en la pantalla durante unos segundos «NEW DATA», que significa que se han validado los parámetros modificados. En pantalla volverá a salir «CHANGE DATE». Girar el botón monomando hasta que aparezca en pantalla «EXIT». J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 23 Pulsar el botón hasta que aparezca «CONFIGURATION». Girar el botón monomando hasta que aparezca en pantalla «EXIT». Pulsar el botón y aparecerá en pantalla el menú principal con la unidad seleccionada. 9.9 Ensayo test vacío Para poder realizar la prueba de vacío seguir los siguientes pasos: Pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS». Girar el botón monomando hasta que aparezca en pantalla «TEST». Pulsar el botón monomando y aparecerá en pantalla «VACUUM TEST». Volver a pulsar de nuevo para seleccionar el test de vacío «ON». Girar el botón monomando hasta que aparezca «EXIT». Pulsar el botón y aparecerá en pantalla «PRESS START». La máquina está preparada para realizar el test de vacio pulsando el pulsador start/stop (4), poniéndose el LED indicador (3) en marcha. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 24 9.10 Ensayo test Bowie-Dick Para poder realizar la prueba de Bowie-Dick seguir los siguientes pasos: Pulsar el botón monomando hasta que aparezca en pantalla el menú «PROGRAMS». Girar el botón monomando hasta que aparezca en pantalla «TEST». Pulsar el botón monomando y aparecerá en pantalla «VACUUM TEST», girar el botón monomando hasta que aparezca «BOWIE-DICK». Pulsar para validar la prueba de BOWIE-DICK «ON». Girar el botón monomando hasta que aparezca «EXIT». Pulsar el botón y aparecerá en pantalla «PRESS START». La máquina está preparada para realizar el test de Bowie-Dick pulsando el pulsador start/stop (4), poniéndose el LED indicador (3) en marcha. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 25 10 Alarmas Durante el funcionamiento se podrán producir algunos fallos que están tipificados en las siguientes condiciones de error: Pantalla J.P. SELECTA s.a. Error Descripción 01 Error EEPROM defectuoso. 02 Error del sensor de presión. Sensor defectuoso o cable cortado. 10 Depósito de agua vacío. 12 Puerta abierta. 13 Sobrepresión. Se ha superado la presión máxima de +2.5bar. 14 Error de vacío. Hay una fuga o la bomba está averiada. 15 Error de presión durante las fracciones. No queda agua o resistencia defectuosa. 16 Sobretemperatura en la caldera. Se ha superado los 150ºC en el interior. 17 Sobretemperatura en la faja. Se ha superado los 150ºC en el exterior. 18 Error de esterilización. Se han superado los márgenes de consigna o queda aire en el interior. 19 No se llega a la consigna. No queda agua o la resistencia está defectuosa. 20 Tarda demasiado tiempo en vaciar la presión y el agua de la caldera. Válvulas o conductos obstruidos. 21 Se ha acabado el papel de la impresora. 22 Error de la impresora. Posiblemente se halla atascado el papel. 23 Error de alimentación (Se detecta en la puesta en marcha). 24 Error en el test de vacío. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 26 11 Recomendaciones para lograr una perfecta esterilización El material a esterilizar, tiene que estar perfectamente limpio, libre cualquier tipo incrustación o residuo, para ello es recomendable lavarlo con un buen detergente y agua destilada. Después aclararlo con abundante agua. No cargar en exceso las bandejas, gradillas o cestillos, procurando dejar siempre un espacio entre ellos de 1 ó 2 cm, a fin de favorecer el paso del vapor y facilitar el secado. 11.1 Esterilización de instrumentos a granel: Colocar el instrumental sobre el papel hidrófugo en posición abierta y que no se toquen entre sí. Evitar colocar en una misma bandeja instrumental de diferente tipo de metal. 11.2 Esterilizar instrumental en bolsas: No debe de haber más de un instrumento por bolsa. Colocar las bolsas sobre papel hidrófugo, en posición vertical que no se toquen entre sí ni tampoco las paredes del autoclave. 11.3 Tubos: Los tubos deben estar perfectamente limpios, aclarados y escurridos. Colocar los tubos, a poder ser, abiertos por ambos lados. Procurar que los tubos no toquen la pared del autoclave, ni que formen dobleces que obstruyan el diámetro interior. 11.4 Recipientes: Nunca colocar recipientes herméticamente cerrados. Colocar los recipientes boca abajo para evitar los depósitos de agua. 11.5 Líquidos: Colocar los líquidos a esterilizar en recipientes preparados para soportar la temperatura de esterilización; y, encima de bandejas, para que se puedan recoger posibles derrames. Los recipientes se llenarán sobre los 2/3 de su capacidad. NO SE CERRARAN herméticamente, se taparán con algodón o algún tipo de tapón que facilite la salida de aire del recipiente y no se forme presión. Se evitará utilizar recipientes de cuello estrecho. Al final del ciclo de esterilización, se dejará que el autoclave se enfríe lentamente (hasta que la presión sea 0 kg/cm²). J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 27 12 Sistemas de protección 12.1 Presostato de Seguridad: Cuando se produce una sobrepresión anormal en la cámara de esterilización, actúa el presostato de seguridad que para la autoclave y abre la electroválvula de aireación. 12.2 Válvula de Seguridad: Si se produjera una sobrepresión anormal se abriría la válvula de seguridad (10) expulsando el vapor. Dicha válvula está calibrada para que inicie la apertura entre 2.2 kg/ cm² y 2.5 kg/cm². En caso de disparo de la válvula de seguridad debe pararse la máquina y avisar al servicio técnico. 12.3 Termostato de seguridad: Cuando se produce una elevación anormal de temperatura o un descenso considerable del nivel de agua (con la consiguiente sobretemperatura en el generador de vapor), entra en funcionamiento el termostato de seguridad (14) parando la calefacción. En caso de bloqueo de la apertura de la puerta por avería del sistema de seguridad seguir el siguiente protocolo: 1 Parar la máquina. 2 Desenchufarla de la red. 3 Poner una tetina y un tubo en la válvula de aireación (11). 4 Abrir la válvula con cuidado para que salga el vapor. Tomar las precauciones necesarias para evitar quemaduras. 5 Esperar el total vaciado del vapor. 6 Con el tirador suministrado con la máquina proceder de la siguiente manera (ver fotos): Mirar con la ayuda de una linterna en el interior de la rejilla de apertura de la tapa; localizar el mecanismo de cierre y verá la palanca de apertura del mismo. Una vez localizado introducir el tirador en la rejilla con cuidado y desplazar la palanca hacia el exterior. Mantener la palanca en esta posición mientras abrimos simultáneamente la tapa mediante la maneta de la puerta. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 28 13 Calibraciones Este apartado describe los parámetros que se pueden cambiar en el nivel de calibración. Estos parámetros deberian cambiarse sólo cuando los valores iniciales seleccionados no satisfagan las necesidades de las aplicaciones. Para poder acceder al nivel de calibración lo haremos del siguiente modo: Aparecerá la pantalla principal. Pulsar el botón monomando y aparecerá la pantalla «PROGRAMS». Girar de nuevo hasta que aparezca «CONFIGURATION». Pulsamos nuevamente y aparecerá en pantalla «LANGUAGE», giraremos el botón hasta que aparezca en pantalla «PASSWORD». Pulsamos el botón y entraremos en la pantalla «ENTER PASSWORD», el código por defecto es «0000» (el usuario puede cambiar la contraseña si lo desea a través de «CHANGE PASSWORD»); pulsar nuevamente y aparecerá «ENTER PASSWORD OK», girar el botón monomando hasta que aparezca «EXIT». Pulsando el botón aparecerá en pantalla «CONFIGURATION», giraremos el botón hasta que aparezca «CALIBRATION», pulsaremos el botón y entraremos dentro de los submenús siguientes: «INTERNAL TEMP» «EXTERNAL TEMP» «PRESSURE» «PREHEAT» «COUNTER» En estos submenús nos permite modificar el cero de las sondas de temperatura y presión, cambiar la consigna de la temperatura de la faja de cada programa y ver el número de esterilizaciones realizada porla máquina. Giraremos el botón hasta encontrar «EXIT», pulsaremos el botón y aparecerá en pantalla «CONFIGURATION» y giraremos nuevamente el botón hasta que aparezca «EXIT». Pulsaremos el botón y volveremos a la pantalla principal. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 29 14 Mantenimiento Antes de quitar la tapa del aparato desconectarlo de la red eléctrica. La placa de control sólo debe ser manipulada por personal de mantenimiento debidamente autorizado. LIMPIEZA: Para la limpieza de las diferentes piezas de los aparatos, recomendamos los siguientes productos: Limpieza del acero inoxidable: Alcohol. Limpieza de carátulas y plásticos: Alcohol con algodón o con un paño no abrasivo. Limpiar el filtro de vaciado de la caldera, situado en la parte inferior. Es aconsejable cambiar el agua después de 50 usos ó 1 vez al mes. 15 Recambios Código J.P. SELECTA s.a. Descripción 13005 Contactor general 15410 Fusible 15520 Filtro 16057 Electroválvula aireado NA 16058 Electroválvula vaciado NC 16059 Electroválvula bomba dosificadora NC 16065 Sensor nivel calderín 16070 Electroválvula de vacío NC 16071 Electroválvula airear bomba NA 16212 Presostato 24213 Bomba dosificadora 24227 Bomba de vacío 32051 Generador de vapor 36027 Solid relé 36033 Boya nivel superior 36034 Boya nivel inferior 45076 Transformador Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 30 16 Esquemas 16.1 Esquemas eléctrico y de potencia C 01 K11 K7 K1 12 14 K7 K1 13 15 FST1 09 10 17 20 18 21 16 03 9V 08 04 14 V K25 20V 02 K11 K26 11 K10 K13 FST2 C 01 Lista de componentes J.P. SELECTA, s.a. Abrera J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 31 4 K21 SENSOR NIVEL 8 + - + - - + Blanco Marrón Azul Comm Nivel Puerta Boya superior Boya Inferior 6-1a + EV3 6-2 9V EV3 1 13V EV6 6-1b EV2 K21 K25 1 EV5 Bloqueo Sonda caldera RS232 Sonda externa 20V Sonda secado Sensor presión EV12 220V Impresora + + - - Bomba llenado Solid Relé secado Ventiladores Bomba vaciado Display Solid Relé caldera Encoder Pulsador ON / OFF J.P. SELECTA, s.a. Abrera J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 32 Abrera J.P. SELECTA, s.a. NC 6-1a J.P. SELECTA s.a. 01 NO NC / 220V AC 17 16 05 08 16 13 09 I5 Lista de componentes 20 NC 02 21 04 NO 10b 10a NC 07 NO 6-1b NC 03 I2 I1 15 14 18 19 12 NC 16.2 Esquema hidráulico Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 33 17 Instruciones complementarias Informaciones y obligaciones del propietario del autoclave en relación con la legislación vigente de equipos a presión: Directiva 97/23/CE Reglamento de aparatos a presión RD 1244/1979 17.1 Instalación: Descarga de la válvula de seguridad: la válvula de seguridad está en la parte posterior del aparato. Está prohibido que frente a esta válvula pueda haber personas, al objeto de evitar daños producidos por un eventual chorro de vapor. Si esto es inevitable, la salida será conducida a lugar seguro, de forma que no pueda causar daños por acción directa del escape 17.2 Legalización de la instalación: La instalación del autoclave debe ser objeto de legalización, ejecutada por un instalador autorizado para esta clase de instalaciones y legalizada de acuerdo con las disposiciones del Art. 14 del Reglamento de Aparatos a Presión. 17.3 Revisiones anuales: Se efectuarán por personal competente, comprobándose el buen estado de funcionamiento y conservación del aparato; se procederá a la comprobación y si procede limpieza o mantenimiento de todos los aparatos de medida, seguridad, automatismos y accesorios. 17.4 Pruebas hidráulicas periódicas: A los 10 años desde la instalación del equipo, y efectuada una revisión anual igual a la indicada en el apartado I.3, se someterá el equipo a una prueba de presión hidráulica de acuerdo con el artículo 16 del vigente Reglamento (1979). La prueba será efectuada por Empresa Instaladora de equipos a presión, por el servicio de conservación del propio usuario o por Empresa de inspección acreditada por la administración. Se levantará acta de prueba, de formato oficial, por triplicado ejemplar, quedando uno en poder del Usuario, otro para la Empresa que ha realizado la prueba y el tercero se remitirá a la Dirección de Industria de la Comunidad Autónoma correspondiente. 17.5 Apertura y cierre de la puerta de carga y descarga: Existen dispositivos de seguridad que bloquean la apertura de la puerta si no existen las condiciones de seguridad para hacerlo. Sin embargo, deben observarse las siguientes precauciones: - La apertura y cierre de la puerta deben ser efectuados por personal previamente informado. - Antes de abrir la puerta el operador se asegurará que el ciclo de trabajo del autoclave ha terminado y de que no existe presión ni nivel de agua en la cámara. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 34 17.6 Precauciones durante la utilización: Se vigilarán periódicamente las indicaciones del display LCD del equipo. No debe superarse en ningún caso la presión máxima admisible (PS = 2,5 bar). 17.7 Mantenimiento - Se comprobará periódicamente el funcionamiento de la válvula de seguridad, presostato, termosstatos, control de nively sondas de presión y tmperatura. - Se comprobará periódicamente el funcionamiento de los demás. - Cuando deban hacerse trabajos de mantenimiento, se despresurizará y enfriará por completo el autoclave y se desconectará de la toma de corriente - Se advierte al personal de mantenimiento que en el autoclave, que está protegido por la carcasa y por tanto no es accesible al personal operador, puede haber partes muy calientes y pueden producirse eventuales escapes de fluidos calientes y a presión, por lo que para acceder a este espacio deben tomarse precauciones tales como: (1) desconectar y enfriar el equipo tal y como se indica más arriba (2) utilizar protecciones adecuadas (3) no manipular aquellos dispositivos que no se conocen, en especial venteos, grifos o conexiones a la atmósfera, por donde se pudiera producir un escape. 17.8 Características del diseño determinantes para la vida del equipo - Fluencia lenta (creep): la temperatura máxima de servicio prevista para este equipo es muy inferior a la temperatura para la cual los materiales empleados presentan deterioro por fluencia lenta. - Fatiga: El equipo ha sido diseñado para resistir con seguridad la presión máxima admisible PS = 2,5 bar, así como la fatiga en los materiales debida a los ciclos de presión (de vacío hasta presión máxima). La vida teórica prevista para el aparato es de 20 años, con régimen de trabajo de 4 operaciones/día 365 días año. En todo caso, la vida real del equipo queda supeditada a las pruebas periódicas de cada 10 años y a las revisiones anuales. - Corrosión: La utilización de acero inoxidable austenítico en la cámara del autoclave garantiza una resistencia a la corrosión adecuada a la acción del agua, vapor y productos a esterilizar. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A J.P. SELECTA s.a. Marzo/07 (It can be modified without notice) Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Page: 35 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 36 1 Safety The Equipment comes complete with safety features. This manual indicates areas of possible risk. 2.1 Safety Icons Identifies risk situations and safety measures that should be adhered to. The icons make reference within the paragraph, marked as a lined grid. Risk danger Risk danger Beware, follow instructions as indicated. Electrical risk Risk of electric shock if accessing zones are shown with this icon. Beware, follow instructions as indicated. Risk of burns in high temperature areas. The temperature in the zone indicated with this icon can exceed 60°C. Use thermal protective gloves to complete described functions. Beware, follow instructions as indicated Important information • Important information in obtaining the best results or optimum performance of the equipment. • Important information to extend the life of the equipment and maintain its optimum performance. 2.2 Risks that the operator can be subjected to: • Possibility of touching surfaces that are over 60°C. • Possible escape of steam vapours. • Electrical risk. 2.3 Qualified users This equipment should only be used by personnel that are qualified users. This equipment should only be used by personnel that have understood this manual or have pervious adequate instruction of the use of steam sterilisers. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 37 2 General information 2.1 Handle the equipment with care. Unpack and check that all items coincide with the delivery note. If you see any discrepancy or damage of any kind, notify your distributor as soon as possible. 2.2 Read this manual before using the equipment. 2.3 These instructions are an important part of the equipment and should be made available to all users. 2.4 If in any doubt or clarity on the use of this instrument, contact your local distributor or the service department of J.P. Selecta, s.a. 2.5 ATTENTION, EQUIPMENT NOT CLEAN AND DISINFECTED SHALL NOT BE REPAIRED. 2.6 Any unauthorised modification, lack of maintenance or deliberate damage to the machine, transgresses the directive 89/655/CEE where the manufacturer will not be responsible for damages that could occur due to undue care and attention. 2.7 Do not use the equipment for fluids that can produce vapours that can form inflammable or explosive mixtures. DO NOT OPEN THE LID OF THE AUTOCLAVE IF THE MACHINE IS NOT CONNECTED TO THE MAINS SUPPLY AND THE MAINS SWITCH IS ILLUMINATED. IF NOT CONNECTED DO NOT FORCE THE DOOR HANDLE. 3 Technical specifications. Código Code Secado Drying 4002514 4002515 Sí Yes 4002425 J.P. SELECTA s.a. Medidas útiles (cm) Capacidad (litros) Chamber dimensions (cm) Capacity (litres) Alto Ø Height Medidas exteriores (cm) Overall dimensions (cm) Alto Height Ancho Length Fondo Width 30 30 40 117 48 62 50 30 70 117 48 62 75 40 60 107 58 72 Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Rango (ºC) Range (ºC) 105 a/to 134 Potencia (W) Power (W) Peso (kg) Weight (kg) 2800 90 3000 108 3600 136 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 38 4 Contents list and accessories 4.1 Standard contents The standard equipment consists of the following items: Description 5600-5601 Code Autester ST DRY PV-II 4002514 Shelf 4002515 5601 4002425 5600 Empying racord 34100 Instruction manual 80206 4.2 Accessories 34100 • Thermal printer, with continuous paper roll, indicating temperature, pressure, time and operating mode. 4002417 • Temperature sensors for internal temperature measurements within the chamber, two applications: - Measured temperature values for a register or thermometer - Used for liquid temperatures or for the measurement of packed item temperatures. • Perforated baskets made from AISI 316 stainless steel. 4002417 Basket code • 1000496 • Autoclave code Number of baskets 20 4002514 2 28 20 4002515 3 38 28 4002425 2 Ø Altura/Height 1000495 28 1000495 1000496 Basket dividers made from AISI 316 stainless steel - 1000495 Dimensions (cm) 1001217 Divider 4 compartments for basket 1000495 1001218 Divider 6 compartments for basket 1000496 Sterilisation drums Ø 1002419 Height Code 4002514 Drum capacity (cm) 1002418 1002418 J.P. SELECTA s.a. 1002418 28 18 4002514 2 1002418 28 18 4002515 3 1002419 35 27 4002425 2 1002419 Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 39 5 Introduction The Autester ST DRY PV II autoclaves are versatile and suitable for a wide range of applications, sanitation, industrial processes and quality control. These autoclaves can sterilise solids, with or without being wrapped, liquids, culture media. They also have disinfecting drying cycles. 5.1 Definitions: 5.2 Sterilisation Sterilisation is the destruction or elimination of all forms of microorganisms, including spores present in inanimate objects. 5.3 Disinfect Disinfection is the process of the destruction of microorganisim agents. The temperature used is less than that of sterilisation. 5.4 Culture media A growth medium or culture medium is any substance in which microorganisims or cells can grow and multiply. Microorganisims can therefore can isolated and used in susceptibility testing. Generally produced as dry powder or granular form, but can also be produced as hydrates and preprepared. Should not be used unless they have been sterilised. 5.5 Prions A prion, short for proteinaceous infectious particle that lacks nucleic acid is a type of infectious agent made only of protein. Characterised by producing illnesses that affect the central nervous system (CNS). Prions are believed to infect and propagate by refolding abnormally into a structure which is able to convert normal molecules of the protein into the abnormally structured form. However, the term in itself does not preclude other mechanisms of transmission. 5.6 Purge The purge cycle is when air is eliminated from the interior of the vessel with the objective of producing saturated steam vapour. 5.7 Saturated vapour Water vapour at a temperature corresponding to the ebullition point of the liquid origin. 5.8 Atmospheric purge The term atmospheric purge is when air is expelled gravametrically by vapour for a determined period. 5.9 Pulsed vacuum purge Purging by pulsed vacuum, combines the heating of the vessel with the extraction of air from within the vessel, by use of a vacuum pump. During this purge cycle the vessel can reach two or three times (model configuration dependent), a high level of vacuum. The purge level by vacuum is more consistent and reliable than that of atmospheric purging. 5.10 Bowie Dick test A Bowie Dick test serves as a verification of the sterilisation by water vapour applied to wrapped products and porous material. 5.11 Vacuum test Verification of the vacuum pump function over a determined time period and that it is adequate for the chamber and the hydraulic circuit under vacuum. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 40 6 Equipment description The Autester ST DRY PV II 30, 50 and 75 litres belong to a series of saturated vapour autoclaves that are distinguished for the following features: 1. 6 point radial locking system 2. External chamber steam generator. 3. Multi functional and totally configurable by the user. 4. Logical menu operation. 5. Can function with a second temperature sensor ( Connected externally.) The installation of the second sensor needs to be factory fitted. 6. RS232 external interface. 6.1 Equipment - Safety system: Safety valve Safety pressurestat Safety thermostat Lid closed detector Protective thermal lid cover. J.P. SELECTA s.a. - External vapour generator chamber - Chamber and lid made from stainless steel 18/8/2 - External case made from stainless steel. - External water source input filter. - Manual release vapour valve. - Select drain valve (drain or tank) - Vacuum pump condenser purge outlet - Exterior water indicator - 10 litre interior water tank - Waste water tank connection. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 41 6.2 Features - Sterilisation temperature controllable from 105°C to 134°C. Sterilisation time from 3 minutes to 59 minutes. Four function modes. 6.3 Operating mode range W ith ou t e x tern al s e ns or W ith ex terna l s en s o r S olid s atm os p he ric purg e 1 05 -134 10 5-1 30 S olid s tw o fra c tion p urg e 1 15 -134 11 5-1 30 S olid s thre e fra c tion p urg e 1 15 -134 11 5-1 30 Liqu id s atm os p he ric purg e 1 05 -134 10 5-1 30 6.4 User programs The Autester ST DRY PV II autoclaves have 10 preset programs that can be modified to the users requirements. ºC Sterilisation time Dry time Purge fraction 0 Instruments not wrapped 134 4 10 2 1 Wrapped instruments 134 12 30 3 2 Prions 134 20 20 3 3 Delicate not wrapped 121 15 15 2 4 Delicate wrapped 121 30 30 3 5 Instruments 126 12 25 3 6 Disinfection 105 25 15 1 7 Liquids 121 30 - 1 8 Solids 121 15 30 1 9 Solids 134 4 30 1 1. Atmospheric purge 2. Vacuum purge two phase 3. Vacuum purge three phase 6.5 Test programs The Autester ST DRY PV II autoclaves have two test programs. - Bowie Dick test Vacuum test Bowie Dick test Vacuum test J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es 134ºC - 3' 30" - 0.7 bar 5' / 8' Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 42 6.6 Control panel 1. 2. 3. 4. 2 LCD Display Single button control LED on indicator Push button Start /Stop 1 3 4 6.7 Manual function control location 5 5. 6. Close/Open door handle Main power switch 7. Water reservior inlet 8. 9. RS232 connection (serial port) External temperature sensor connection (Pt100) 10. 11. 12. 13. 14. 15. 16. 17. Safety valve Vapour release valve External water source connection Air filter Safety thermostat Water tank outlet Pump condenser outlet Drain valve 6 7 8 9 10 11 12 13 14 15 16 17 J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 43 7 Installation 7.1 Locate the autoclave close to an appropriate power source. 7.2 The autoclave needs to be placed on a flat stable horizontal surface, leaving a minimum space of 10 cm around the instrument. 7.3 Adjust the front feet to level the autoclave and set the autoclave in position. 7.4 Fix a plastic or rubber hose to the pump condenser connection with a receptical to collect any condensate produced by the vacuum pump when in the purge mode. Place the receptical no higher than the out let. 7.5 EXTERNAL WATER SOURCE INLET: 7.5.1 The autoclave can be filled from a mains water source through a 3/4" connection as indicated in the picture. Maximum water pressure to be no greater than 2 bar. This feature needs to be configured. See chapter 9.6. ATTENTION Do not use the waste water option until a suitable tube is connected to the outlet, Needs to withstand high pressure and high temperature ( Pressure hose). Fix the tube in place so that it cannot be forced off by the pressure of the outlet waste. Do not touch the tube while in operation, can cause severe burns. 7.6 DRAIN SYSTEM SELECTION: 7.6.1 J.P. SELECTA s.a. With the valve indicated in the picture, if you want to recycle/reclaim the water, locate the control valve lever towards the inside of the machine as shown. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A 7.6.2 Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 44 To drain waste to an external drain, at the end of each sterilisation process, waste will be drained externally. Set the control valve lever position away from the equipment. Fix a tube to the outlet and locate the other end to a drain or external collection vessel. ENSURE THAT THE OUTLET TUBE IS NOT KINKED OR OBSTRUCTED. ATTENTION! the steam outlet from valve (11) and the outlet of waste water and steam from valve (17) are at HIGH PRESSURE AND TEMPERAURE. Take all precautions to avoid SERIOUS BURNS. NEVER HOLD THE OUTLET PIPE OR VALVE (17) WITH YOUR HAND AS IT WILL CAUSE SERIOUS BURNS. 7 8 Operation 8.1 SWITCH ON Activate the main power switch (6), Fill the reservoir (7) with approximately 8 litres of water. Check that the vapour release valve (11) is closed. Place the items to be sterilised inside Close the lid. NOTE If this is the first process from cold the machine will require to heat up for 10-15 minutres from initial switch on. Preheating: Plug in, switch on the mains switch, leave for 10-15minutes to heat up. 8.2 PROGRAM Once the mains switch (6) is on, the display after few seconds shows a start message: Software version - Model Thereafter a default message corresponding to the last program used will be shown. If the program shown is the one to be used, the system can be started with the start/stop button; LED (3) will then light up. To select different operating parameters see instruction 9, diagram and menu, where parameter changes to optimise the instruments function can be made. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 Marzo/07 (It can be modified without notice) Page: 45 9 General Diagram and menu INSTRUCTION MANUAL CODE 80206 REV A J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 46 9.1 Program Selection If the program required is not shown on the screen, push the single button control once, the screen will show «PROGRAMS». Push the button once more Rotate the single button control to the program you require. Once the program has been located, push the button again, «Select» will appear, push the button to enter the program selected. After a few seconds a confirmation of «SELECTED» will be shown. Finally the selected program will appear on the screen. Push the Start/ Stop button, the LED will light up and the equipment will start the sterilisation cycle. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 47 9.2 To Modify programs If the program settings you require are not on the set programs you can change the program parameters. By means of the menu «PROGRAMS» as before using the single control, turn the button to select the closest program to what you require, we will now modify this program . By pressing the single button control, «SELECT» will appear, this time rotate the button until «MODIFY» is shown on the screen, push the button again, the program you want to modify will appear in the screen. Rotate the button to the parameter to be changed and press the button, rotate again to view the parameter selection and press to confirm your choice. Once the program change has been made press the button and «SELECT» will appear once again, if more than one parameter is to be changed rotate to «MODIFY» again and repeat the process for the second parameter. After all modifications have been made press the button when «SELECT» is displayed, this will validate the changes, after a few seconds «SELECTED» will be shown. Finally the new modified program will be shown on the screen. Push the Start/ Stop button, the LED will light up and the equipment will start the sterilisation cycle. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 48 9.3 Change Language To change the language, push the single button controller ,«PROGRAMS» will appear in the menu. Rotate the button until «CONFIGURATION» appears on the screen; push the button, the screen will now show «LANGUAGE». Push the button once more and the screen will show the default language, Now turn the button to the language of choice, push the button to confirm your choice, «SELECTED» will now be displayed. Rotate the button again until «EXIT» appears. Push the button, the screen will display «CONFIGURATION». Rotate the button until the screen displays «EXIT». Push the button and the main menu with the language of choice will appear. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 49 9.4 Configure Units °C-°F In case that you are required to change the units of measurement, push the single control button once and the screen menu will display «PROGRAMS». Rotate the button to show «CONFIGURATION» on the screen. Push the button to confirm and «LANGUAGE» will appear, turn the button through the submenu to indicate «UNITS» Push the button and change from Celsius to Farenheit. Rotate the button again until «EXIT» appears. ( Exit from the sub menu) Push the button again and «CONFIGURATION» is shown. Rotate the button so that «EXIT» is displayed, (Exit out of the main menu.) Push the button again and the principal menu will be displayed with the selected unit of measurement. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 50 9.5 Configure printer option To activate and configure the printer, push the single button control until «PROGRAMS» appears on the screen. Rotate the button until «CONFIGURATION» appears. Push the button to enter the submenu and «LANGUAGE» is shown, rotate the button until «PRINTER» is shown. Push the button to confirm and the screen will display «PRINTER STATUS». Push the button again and «ON» appears, this will activate the printer. Rotate the button and «PRINT INTERVAL» will be display. Push the button to change the time interval in minutes. Rotate the button until «PRESS BUTTON» is displayed. If you are replacing a paper roll continue to push the buton to advance the paper. Rotate the button until «EXIT» appears on the screen. Push the button and «CONFIGURATION» will be displayed. Rotate the button until «EXIT» is shown. Push the button and the main menu will be displayed with the printer activated. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 51 9.6 Configure external water source. If you are using mains water, the machine needs to be configured in the following way: Push the single button control, the menu will display «PROGRAMS» Rotate the button to display «CONFIGURATION». Push the button and «LANGUAGE» will be displayed, rotate the button until the submenu displays «EXTERNAL WATER» J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 52 Push the button to confirm, this will activate the valve and the «ON» will be displayed. Rotate the button until «EXIT» is shown. Push the button and the menu will display «CONFIGURATION» Rotate the button to display «EXIT» on the screen. Push the button and the main menu will be displayed. 9.7 Configure external probe If you want to use a second temperature probe, it needs to be configured in the following manner: Push the single button control in the main menu to display «PROGRAMS» Rotate the button until «CONFIGURATION» is displayed. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 53 Push the button and «LANGUAGE» will appear, rotate the button in the submenu to «EXTERNAL PROBE». Push the button to activate the second external temperature sensor «ON» Rotate again to display«EXIT» Push the button and «CONFIGURATION» will be displayed. Rotate the button until «EXIT» is displayed in the screen Push the button to confirm and return to the main menu, the second sensor probe data will now be displayed. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 54 9.8 Configure time To configure the time, push the single button control in the main menu «PROGRAMS» will be displayed. Rotate the button and «CONFIGURATION» will be shown on the screen. Push the button, the screen will display «LANGUAGE». Rotate the button in the submenu to «CLOCK». Push the button until «CHANGE DATE» appears. Push the button again and the screen will display the clock parameters. Once the parameters have been set by pulsing the button, after a few seconds «NEW DATA» will be displayed, this shows that the modified parameters have been accepted. Exit from the screen again by pushing the button «CHANGE DATE» will be displayed. Rotate the button to display «EXIT». J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 55 Push the button and again «CONFIGURATION» will be displayed. Rotate the button until «EXIT» appears. Push the button confirm and the main menue will once again be displayed. 9.9 Vacuum test To complete the vacuum test continue as follows: Push the single button control until the menu displays «PROGRAMS» Rotate the button until «TEST» is displayed. Push the button and «VACUUM TEST» will be shown on the screen. Push the button again to select vacuum test «ON». Rotate the button to display «EXIT» Push the button and the screen displays «PRESS START». The machine is now ready to complete the vacuum test, push the start/stop (4) button, the Red LED (3) will light up. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 56 9.10 Bowie-Dick Test To complete the Bowie-Dick Test follow the instructions below: Push the button in the main menu to display «PROGRAMS» Push the button to display configuration Rotate the button to display «TEST». Push the button and «VACUUM TEST» will appear, rotate the button again to display «BOWIE-DICK». Push the button to confirm BOWIE-DICK «ON». Rotate the button until «EXIT» appears. Push the button and the screen will display «PRESS START», The machine is ready to complete the Bowie-Dick test. Initiate the test by pressing the start/stop (4) button the red LED (3) will light up. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 57 10 Alarms and errors If during operation a fault occurs a message will appear, these are indicated by showing ERROR on the screen: Display J.P. SELECTA s.a. Error Description 01 Error EEPROM faulty. 02 Pressure sensor Error Faulty sensor or disconnected cable. 10 Water reservoir empty. 12 Lid / Door open 13 The pressure has superseded the maximum admissible pressure of +2.5bar. 14 Vacuum Error. Vacuum leak or faulty pump. 15 Pressure Error during purge phase. Insufficent water or faulty water heater. 16 Over temperature Error, The internal temperature has exceeded the maximum limit of 150°C 17 Over temperature error, external temperature has exceeded 150°C. 18 Sterilisation Error. The margin of error for sterilisation has been superseded or there was still air in the chamber during the sterilisation. 19 Error set value not reached. No water in the system or heater fault. 20 Empty error, takes too long to empty the system. Valves or drain blocked or faulty. 21 Error no Paper, Printer requires paper. 22 Printer Error, Paper jam. 23 Power Error, Power failure (detected in the main power source) 24 Vacuum Test error. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 58 11 Recomendation to achieve a perfect sterilisation The material to be sterilised needs to be clean, free from any encrusted or residual material, we recommend that they be washed in a good detergent and distilled water, then rinsed with distilled water. Do not overload the baskets, drums or trays, always leave a space of 1 to 2 cm between items to allow a free passage of vapour and to ease drying. 10.1 Sterilisation of instruments in bulk. Place the instruments on a tray with water repellent paper leaving a space between each instrument. Try to keep similar type material instruments together on a tray. 10.2 Sterilise instruments in pouches or bags: Only place one instrument per bag. Place the bags on water repellent paper in a vertical position so that they do not touch each other or the wall of the autoclave, use a rack if available. 10.3 Tubing: The tubing need to be clean and drained. Place the tubing so that the openings on both ends are open. Make sure that the tubes are not touching the autoclave wall, blocked or twisted and that nothing can block the inside. 10.4 Vessels: Never put hermetically sealed vessels in the autoclave. Place the contents open end down to prevent any residual water being left inside. 10.5 Liquids Place the receptacle with the liquid inside on a drip tray, making sure that the receptacle can withstand the temperature. Do not fill the receptacle more than 2/3rds of its maximum capacity, DO NOT CLOSE THE LID IF IT HAS A HERMETICAL SEALED, only us a lid if the pressure can be released. (eg. Serotap or Bacti-lid) Try to avoid using narrow neck vessels. At the end of the cycle, let the autoclave cool down slowly (until the pressure is 0 kg/cm²) J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 59 12 Protection system 11.1 Safety pressurestat: If the pressure increases above the normal value permitted in the chamber, the safety pressurestat is activated which stops the autoclave and opens the air valve and releases the pressure. 11.2 Safety valve: If the pressure increases over the normal value, the over pressure valve opens, releasing the pressure (valve 10). This valve is calibrated to release the pressure at 2.2 kg/cm² and 2.5 kg/cm². If the valve is triggered, stop the machine and call your nearest service department. 11.3 Safety thermostat: If the temperature increases over the normal level, or a considerable decrease in water level produces a sudden over temperature in the vapour generator, the over temperature safety valve will activate (14), cutting power to the heater element. To be used by service personnel only. If there is a blockage or the opening of the lid is prevented by the safety system, follow the safety protocol below to release the pressure and lid: 1 Stop the machine. 2 Unplug at the mains 3 Put a tube over the air valve (11) 4 Open the valve with care so that the vapour pressure can be released. Take care to prevent burns or scalds. 5 Wait until all the vapour and pressure is released. 6 With the manual opening hook supplied with the autoclave, proceed in the following manner (see Photos.): Look through the grill with the aid of a torch locate the lid mechanism, lever. Once located place the hook through the grill onto the lever and pull the leaver outwards. Hold the lever in place while simultaneously opening the lid. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 60 13 Calibration To be used by qualified service personnel only. This section describes the parameters that you can change to maintain the correct calibration. These parameters should only be changed if the values selected do not satisfy the application requirements. To gain access to the calibration level follow the instructions below: Displayed on the main screen Press the single button control, «PROGRAMS» will be displayed. Rotate the menu to «CONFIGURATION». Push the button and «LANGUAGE» will be shown on the screen, rotate the button until «PASSWORD» is shown. Press the button and the screen will display «ENTER PASSWORD», the code by default is «0000» (the user can change this password if they wish by selecting «CHANGE PASSWORD»); push the button again and the screen displays «ENTER PASSWORD OK», rotate the button to «EXIT». Press the button and the screen will display «CONFIGURATION», rotate the button to «CALIBRATION», push the button and within the sub menu are the following: «INTERNAL TEMP» «EXTERNAL TEMP» «PRESSURE» «PREHEAT» «COUNTER» These sub menus permit the modification of the Zero calibration of the temperature and pressure sensors, change the fixed temperature entry of each program and observe the number of serialisations completed by the machine. Rotate the button to «EXIT», push the button and «CONFIGURATION» will be shown, rotate the button again to «EXIT». Push the button and return to the main screen. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 61 14 Maintenance Before removing the lid disconnect the machine from the mains. The control board should only be changed by maintenance or authorised personnel CLEANING: To clean the differing parts of the machine the following cleaning products are commended: To clean the stainless steel: Alcohol. To clean the cover and plastic areas: use cotton wool dipped in Alcohol or use a non abrasive cloth with Alcohol. Clean the vacuum filter, placed at the back of the machine. It is recommended that the vacuum filter be changed after every 50 cycles or once every month. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 62 15 Schematic 15.1 Power circuit schematic C 01 K11 K7 K1 12 14 K7 K1 13 15 FST1 09 10 17 20 18 21 16 03 9V 08 04 14 V K25 20V 02 K11 K26 11 K10 K13 FST2 C 01 Lista de componentes J.P. SELECTA, s.a. Abrera J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 63 4 K21 SENSOR NIVEL 8 + - + - - + Blanco Marrón Azul Comm Nivel Puerta Boya superior Boya Inferior 6-1a + EV3 6-2 9V EV3 1 13V EV6 6-1b EV2 K21 K25 1 EV5 Bloqueo Sonda caldera RS232 Sonda externa 20V Sonda secado Sensor presión EV12 220V Impresora + + - - Bomba llenado Solid Relé secado Ventiladores Bomba vaciado Display Solid Relé caldera Encoder Pulsador ON / OFF J.P. SELECTA, s.a. Abrera J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 64 NC Abrera J.P. SELECTA, s.a. NC J.P. SELECTA s.a. 01 NO NC / 220V AC 17 16 05 08 16 13 09 I5 Lista de componentes 20 NC 02 6-1a 04 NO 10b 10a NC 07 NO 6-1b 03 I2 I1 15 14 18 19 12 NC 15.2 Hydraulic schematic Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A Marzo/07 (It can be modified without notice) Page: 65 17 Complemetary instructions Informations and obligations of the owner of the autoclave in relation to the current legislation to the pressure eqquipment. Directive 97/23/CE Reglamento de aparatos a presión RD 1244/1979 17.1 Installation: Safety valve discharging:: The safety valve is placed on the rear part of the aparatus.. Is forbiden that people can be stay in forn of the safety valve in order to avoid damages produced by a possible steam lakage. If that is inevitable its steam outlet will be carried to a safe zone, in a way that it cannot cause damages by the direct acction of the steam lakage. 17.2 Legalization of the installation: The installation of the autoclave must be object of legalization done by an authorized engeneer specialized on these kind of installations; he or she has to test it acording with the Article 14 of the Presure Aparatus Regulations. 17.3 Annual review They have to be done by competent personel who must check the good contition preservation and working of the equipment.; He or she must check and, if necessary, clean and repair all measurement and safety devices and all other devices. 17.4 Periodic hidraulic tests: After 10 years from the equimment installation, once made a review as explained on the section I.3, the vessel must pass an hidraulic test acording with the article 16 of the current Regulations (1979). The test will be made by a Installer Society of pressure equipments, by the maitenence service of the owner or by an oficial aproved society. They will write a minutes in triplicate. One of them will be keeped in hands of the owner, other to the society which made the test and the last one to the goverment desk in charge of control this kind of equipment. 17.5 Aperture and closing of the loading and unloading lid: The autoclave includes safety devices which blockes the lid aperture if there are not the proper safety conditions. Nevertheless you must to take the following precautory measures: - The aperture and clossing of the lid must be done by previously informed personel. - Before to open the lid the user will make sure that the sterilization cycle finished and that there is no pressure or water level inside the chamber J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 66 17.6 Precautionary measures during the use: The user must watch often the information on the LCD display of the autoclave. In any must not be excedeed the maximal allowable pressure (PS = 2,5 bar). 17.7 Maintenance - Must be done periodic check-ups of the following safety devices: (1) Safety valva (2) Maximal limit pressure switch (3) Safety thermostat - Must be done periodic check-ups of the other devices. - While we were doing maitenence works the chamber must be cold and unpressured. It also must be disconnectd from the mains plug. - Is noticed to the maitenence personel that the chamber is protected by a chasis so is cannot be touched by the users. The autoclave may have very hot parts and could cause possible water and steam lakage, so they must enter in the room keeping precautionary measures like: (1) Disconnect the autoclave from de mains and leave it get cold as it was write before (2) Use suitable protections (3) Do not handle the devices which do not know, specially air vents, valves or other piping conexion which may cause lakages. 17.8 Desing features which are determinant to the equipment life - Slow creep: the maximal service temparature planed is smaller than the one at the used materials could get deteriorated by slow creep. - Fatigue: The equipment was designed to resist safety the maximal alowed pressure PS=2.5 bar, and the fatigue caused by the pressure cycles (from the vacuum to the maximal presure). The supposed life of the apparatus is 20 years with a working rate of 4 operations each day, 365 days a year. Any way the real life must be determined by the annual check-ins... - Corrosion: The use of stainless steel type 1.4404 (316L) to make the chamber sure a suitable corrosion durability under the water, steam and products to be sterilized action. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362 INSTRUCTION MANUAL CODE 80206 REV A J.P. SELECTA s.a. Marzo/07 (It can be modified without notice) Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Page: 67 Tel 34 937 700 877 Fax 34 937 702 362 MANUAL DE INSTRUCCIONES CODIGO 80206 REV A Marzo/07 (Sujetas a modificaciones sin previo aviso) Pag.: 68 PROGRAMA DE FABRICACIÓN / MANUFACTURING PROGRAMME - Agitadores magnéticos. / Magnetic stirrers. - Agitadores orbitales, rotativos y vibradores. / Orbital, rotary and vibratory stirrers. - Aparatos para anatomía e histología. / Clinical and biotechnological instruments. - Aparatos a baja temperatura. / Low temperature apparatus. - Aparatos de regulación y control. / Regulation and control. - Arcones conservadores. / Chest freezers. - Armarios conservadores para bancos de sangre. / Blood bank storage cabinet. - Armarios para ensayos de germinación de plantas. / Plant germination incubator. - Autoclaves para esterilización. / Autoclaves. - Baños de limpieza por ultrasonidos. / Ultrasonic cleaners. - Baños termostáticos. / Thermostatic baths - Baterías de kjeldahl y baterías de soxhlet. / Kjeldahl battery and Soxhlet battery. - Centrífugas de sobremesa y refrigeradas. / Centrifuges. - Estufas bacteriológicas y de cultivos. / Bacteriological and culture ovens. - Estufas desecación al vacío. / Vacuum ovens - Estufas para desecación y esterilización. / Drying and sterilization ovens. - Estufas para desecación y esterilización por aire forzado. / Drying and sterilizing ovens by fan convection. - Extractor para determinación de celulosa y fibra / Extractor for Determination of Cellulose and Fibre. - Extractor para determinación de grasas. / Extractor for the Determination of Fats in Food and Oils. - Hornos de mufla hasta 1.150°C. / Muffle furnaces up to 1,150ºC. - Instrumental en acero inoxidable, niquel y zirconio. / Instrumental in stainless steel, nickel and zirconium.. - Mantas calefactoras. / Heating mantles. - Placas calefactoras. / Hotplates. - Termostatos de inmersión. / Immersion thermostats. - Termostatos de bloque metálico para tubos y digestores kjeldahl. / Metallic block thermostats. - Ultratermostatos de circulación. / Circulation ultrathermostat. - Unidad de destilación para proteinas. / Distiller for proteins. - Viscosímetros. / Viscometers. J.P. SELECTA s.a. Ctra. NII Km 585.1 Abrera 08630 (Barcelona) España e-mail: selecta @jpselecta.es - website: http://www.jpselecta.es Tel 34 937 700 877 Fax 34 937 702 362
