MOTORIZED VEHICLES DIVISION
Connector Solutions for
Automotive Applications
2
About FCI
With operations in
30 countries and sales
of 1.25 billion euros in
2008, FCI is a leading
manufacturer of
connectors. Our 13,000
employees are committed
to providing customers
with high-quality, innovative
products for a wide range
of consumer and industrial
applications.
For more information:
www.fci.com
FCI Motorized Vehicles offers a comprehensive range of reliable,
high-tech and innovative solutions for every automotive application.
We manufacture and supply connectors for engine, cockpit, safety and
other electronic applications.
We have the global footprint and Core Competence Centers to support
customers on a global basis. We employ nearly 4 000 people and
manufacture our products in plants located in all regions.
In our 5 engineering competence centers, we have dedicated engineers
who – in a combined effort – develop innovative interconnect solutions
adapted to your needs and requirements.
Through outstanding quality, cost competitiveness and delivery
performances, we are recognized by our customers as a solution
provider and their strategic partner.
This document is non-contractual and is for information purposes only.
The supply of some products displayed in this brochure might be limited to some customers.
For more information, please contact your local sales office.
FOCUS, COMMITTED, INVENTIVE
3
4
FCI PRODUCT OFFERING FOR HIGH END
INTERCONNECTION SOLUTIONS
Active safety
(ABS-ESP)
Cable
Assemblies
Lighting
Modules
(doors, seats)
Signal
Terminal
Systems
Power
Terminal
Systems
Power
distribution
Sensors, Injectors
& actuators
Powertrain Electronics
Passive Safety Restraints Convenience & Mutimedia
5
www.fciconnect.com
FCI is a world leader in providing cost-effective and innovative terminals systems, wire to wire, wire to device,
wire to circuit board, flex interconnect, squib interconnects, ECU packages, pin-headers, high end cable
assembly connector solutions and associated application tooling covering applications such as engine
compartment, body & chassis, cockpit and multimedia.
How to use our catalog?
In this catalog, you will find an overview of our main product ranges accompanied by some of our most
commonly used part numbers within each connector family.
Using those references you can go directly to the FCI website home page, www.fciconnect.com, enter the
part number in the search box and see the full datasheet and drawing for that part.
Enter the part
reference in FCI website
to see full datasheet
& drawing for that part
Body & Chassis Engine Cockpit
